Model : RE-100P

Evaporating Flask Volume : 50-2000ml(Standard configuration-1000ml)
Receiving Flask Volume : 100-2000ml(Standard configuration-1000ml)
Speed Range : 20rpm-280rpm
Heating Temperature Range : Room temp. to 180℃
Stroke Displacement : Automatic 150mm
This rotary evaporator is exclusive to academic institutions and meets all your basic needs for evaporation.

Model : RE-100S

Speed Range : 20-200rpm
Display : LED (Speed, temperature, time)
Heating Temperature Range : Room temp. to 180℃
Stroke Displacement : Manual 110mm + auxiliary 100mm
This rotary evaporator meets all your basic needs for evaporation. Features include a manual lift, 5L bath capacity and digital temperature display.

Model : RE-200P

Speed Range : 10rpm~150rpm
Display : LCD (Temperature/speed/clockwise and Anti-clockwise/time)
Heating Temperature Range : Room temp. to 180℃ (Both water and oil)
Heating Bath Size : Φ450mm×240mm
Stroke Displacement : Automatic 180mm
This rotary evaporator meets the highest expectations of convenience and versatility.

Model : RE-2000M; RE-3000M; RE-5000M

Rotation Speed : 0–310 rpm/min
System Vacuum : 2 mbar
Oil bath : RT–210 °C ±2 °C
Temperature Range : Water bath: RT–99 °C ±0.5 °C
Evaporation Capacity : Max. 25; 100; 150 mL/min
The rotary evaporator provides an efficient, safe, and versatile solution for solvent evaporation, concentration, and distillation in various laboratory applications.

Model : RE-1000H; RE-2000H
Flask Capacity : 1000; 2000 mL
Rotation Speed : 0–310 rpm/min
Evaporation Capacity : Max. 25 mL/min
Temperature Range : Water bath: RT–99 °C ±0.5 °C; Oil bath: RT–210 °C ±2 °C
The rotary evaporator integrates advanced functionality with user-centric design, ideal for efficient and safe solvent recovery, concentration, and distillation processes in laboratories.

Model: RE-2000AR; RE-2000BR; RE-2000CR

Rotating Flask Capacity: 1 L (optional 2 L)
Receiving Flask Capacity: 1 L (optional 2 L)
Condensation Area: About 0.17 ㎡
Maximum Evaporation Capacity (Water): About 0.9 L/h
Rotational Speed: 0–200 rpm
Lifting Travel Range: 0–150 mm
The digital display ensures higher precision for your experimental measurements.

Model: RE-3000AR; RE-3000BR; RE-3000CR

Rotating Flask Capacity: 3 L
Receiving Flask Capacity: 2 L
Condenser Size (Dia.×H): 90×430 mm
Maximum Evaporation Capacity (Water):About 1.5 L/h
Rotational Speed: 20–200 rpm
Lifting Travel Range: 0–150 mm
Rotary evaporator enables fast, gentle solvent removal under reduced pressure for laboratory concentration and purification.

Model: RE-50R; RE-50RC

Rotating Flask Capacity: 500 mL
Receiving Flask Capacity: 500 mL
Condensation Area (㎡): About 0.17 ㎡
Maximum Evaporation Capacity (Water): About 0.9 L/h
Rotational Speed: 0–120 rpm
Lifting Travel Range: 0–120 mm
RE-50R and RE-50RC adopt loose phillips screw, allowing the host to be tilted for enhanced operational flexibility.

Model: RE-201R

Rotating Flask Capacity: 1 L
Receiving Flask Capacity: 1 L
Condensation Area (㎡): About 0.12 ㎡
Maximum Evaporation Capacity (Water): About 0.9 L/h
Rotational Speed: 0–120 rpm
Lifting Travel Range: 0–140 mm
Equipped with a vacuum gauge, the rotary evaporator can intuitively display the current vacuum level.

Model: RE-301R; RE-501R

Rotating Flask Capacity: 3 L; 5 L
Receiving Flask Capacity: 2 L; 3 L
Condensation Area (㎡): About 0.2; 0.27
Maximum Evaporation Capacity (Water)(L/h): About 1.5; 2
Rotational Speed: 0–120 rpm; 0–90 rpm
Lifting Travel Range: 0–140 mm; 0–120 mm
Adopting multi-layer serpentine glass condenser tubes to ensure high recovery rate.

Model: RE-1000R; RE-2002R; RE-3003R; RE-5005R

Rotating Flask Capacity: 10 L; 20 L; 30 L; 50 L
Receiving Flask Capacity: 5 L; 10 L; 20 L
Condensation Area (㎡): About 0.57; 1.2; 1.28; 1.5
Evaporation Rate (Water) (L/h): 3.2; 5; 9
Rotational Speed: 0–120 rpm; 0–90 rpm
Lifting Travel Range: 0–180 mm
The bottom of the receiving flask is equipped with a piston, allowing quickly recovery of solvents.

Model: RE-5200R; RE-5220R; RE-5250R

Rotating Flask Capacity: 10 L; 20 L; 50 L
Receiving Flask Capacity: 5 L; 10 L; 20 L
Condensation Area (㎡): About 0.57; 1.2; 1.5
Evaporation Rate (Water) (L/h): 3.2; 5; 12
Rotational Speed: 0–120 rpm; 0–90 rpm
Lifting Travel Range: 0–180 mm
Dual-stage condensation system for enhanced cooling efficiency and improved vapor recovery.

Model: RE-5000R

Rotating Flask Capacity: 5 L
Receiving Flask Capacity: 3 L
Condensation Area (㎡): About 0.27 ㎡
Maximum Evaporation Capacity (Water): About 2 L/h
Rotational Speed: 20–200 rpm
Lifting Travel Range: 0–150 mm
The electric lifting device enables the host to be lifted and lowered within the range of 0–150 mm.

Model: RE-5300R

Rotating Flask Capacity: 500 mL
Receiving Flask Capacity: 500 mL
Condensation Area (㎡): About 0.17 ㎡
Maximum Evaporation Capacity (Water): About 0.9 L/h
Rotational Speed: 0–120 rpm
Lifting Travel Range: 0–120 mm
Loose Phillips screw tilt the Rotary Evaporator RE-5300R freely within the range of 0–15 degree.

Model: RE-6000R

Rotating Flask Capacity: 6 L
Receiving Flask Capacity: 3 L
Condensation Area (㎡): About 0.5 ㎡
Rotational Speed: Start–120 rpm
Lifting Travel Range: 0–150 mm
An integrated LCD screen is utilized to display temperature and rotational speed.
