Centered on intelligent upgrades and user-friendly design, our rotary evaporators are tailored to meet the diverse needs of various scenarios—including routine laboratory operations, small-scale production, and scientific research training. By making every evaporation, concentration, and purification process more effortless, efficient, and safe, we provide users with a cost-effective, professional solution.
Rotary Evaporator Feature:
Integrated design eliminates the need for separate circulating chillers and vacuum controllers, enabling more efficient space utilization.
Smart touchscreen control, clear, intuitive, and adjustable with a single touch.
High-thermal-conductivity metal condenser with superior heat transfer performance, RE-100CV can rapidly lower the temperature by 40 °C within just 5 minutes.
Intelligent energy-saving control system automatically shuts down the refrigeration unit under extremely low-temperature operating conditions, significantly lowering electricity costs as well as expenditures on cooling media consumables.
Dual stainless steel spring seal combined with PTFE sealing technology, it offers superior sealing performance and exceptional corrosion resistance.
One-touch simultaneous activation of the chiller, heating bath, vacuum controller and rotation function, or independent start-up of each component.
Running curves can be viewed in real time during operation, with up to 5 frequently used program files saveable.
Up to 5 frequently used program files can be edited and saved.
Rotary Evaporator Specification:
| Model | RE-100CV |
|---|
| Speed Range | 20–280 rpm/min |
| Rotary Direction | Clockwise and Anti-clockwise |
| Lift mechanism | Automatic/150 mm |
| Display | LCD Touchscreen |
| Evaporation Flask / Collection Flask Capacity | 1 L |
| Heating Bath Capacity | 3.5 L |
| Evaporation Capacity | Max. 1.56 L\h |
| Heating Temperature Range | Water bath: RT–99 °C, ±1 °C |
| Oil bath: RT to 180℃, ±3 ℃ |
| Heating Power | 1300 W |
| Condenser Temperature Range | RT to -40 ℃, ±3℃ |
| Cooling Power | 725 W |
| Temperature Setting Accuracy | ±0.1 °C |
| Time Setting Range | 1–999 min |
| Vacuum Setting Range | 1–1000 mbar |
| Control Mode | Single-point control mode, Programmed control mode |
| Control Program | Store up to 5 programs, each containing 5 steps control |
| Ambient Temperature and Humidity | 5–40 ℃, 80% RH |
| Protection Class | IP20 |
| Power Supply | 100–120/200–240 V, 50/60 Hz |
| Consumption | 3000 W |
| External Size (W×D×H) | 451×413×737 mm |
| Packing Size (W×D×H) | 945×515×1035 mm |
| N.W./G.W. | 77/87 kg |
