Rotating Flask Capacity: 6 L Receiving Flask Capacity: 3 L Condensation Area (㎡): About 0.5 ㎡ Rotational Speed: Start–120 rpm Lifting Travel Range: 0–150 mm
An integrated LCD screen is utilized to display temperature and rotational speed.
1. The structural adopts an upright style, making full use of space to arrange rotating, evaporating, condensing, and receiving devices, with a small footprint.
2. The sealing element adopts a dual seal composed of Teflon and fluororubber, with good air tightness and long service life, and can be regularly disassembled, cleaned or replaced.
3. The condenser made of high-temperature-resistant glass, featuring a double reflux design and flange port, paired with flange port receiving flask for quick assembly and disassembly.
4. Adops AC motor, electronic stepless speed regulation, and synchronous belt drive device. Increase the diameter of the transmission shaft tube, so the evaporation pipeline is 1.5 times larger than that of general instruments, improving evaporation efficiency.
5. Integrated LCD screen, used for displaying temperature and speed, clear and beautiful.
6. The constant temperature bath pot is made of 304 stainless steel and can be adjusted to the appropriate position by electric lifting.
Water bath, RT to 99 ℃; oil bath, RT to 180 ℃ (can customize higher temperature oil bath pot for RT to 260 ℃)
Bath Pot
Inner Liner Material
304 stainless steel
Inner Liner Size (Dia.×H)(mm)
320×180 mm
Capacity
About 6 L
Heating Power
3 kW
Size (D×W×H)
≈900×800×1200mm
Shipping Size (D×W×H)
1000×900×1000 mm
G.W.
70 kg
Recommended Equipment (excluding)
Circulating water vacuum pump VP-95BW and low-temperature coolant circulation pump LTC-1040
Advantage:
1. The structural adopts an upright style, making full use of space to arrange rotating, evaporating, condensing, and receiving devices, with a small footprint.
2. The sealing element adopts a dual seal composed of Teflon and fluororubber, with good air tightness and long service life, and can be regularly disassembled, cleaned or replaced.
3. The condenser made of high-temperature-resistant glass, featuring a double reflux design and flange port, paired with flange port receiving flask for quick assembly and disassembly.
4. Adops AC motor, electronic stepless speed regulation, and synchronous belt drive device. Increase the diameter of the transmission shaft tube, so the evaporation pipeline is 1.5 times larger than that of general instruments, improving evaporation efficiency.
5. Integrated LCD screen, used for displaying temperature and speed, clear and beautiful.
6. The constant temperature bath pot is made of 304 stainless steel and can be adjusted to the appropriate position by electric lifting.
As a professional lab and medical equipment manufacturer, Scitek Global is certified by ISO 9001, ISO 13485, ISO 45001 and ISO 14001. Almost all our products are certified by ETL, CE and FDA .
Scitek Global looks forward to establishing cooperation with more distributors all over the world, and working together to create greater customer value.
