Model: LTC-2010; LTC-2020; LTC-2040

Lift Head : 8 m
Compressor : 2/ 3 P
Refrigerant : R22/ R404
Liquid Storage Capacity : 20 L
Bath Opening Diameter : 300 mm
Circulating Pump Flow Rate : 17 L/min
Temperature Range : -10 ℃–RT/ -20 ℃–RT/ -40 ℃–RT
Designed to efficiently circulate coolant in systems requiring precise temperature control at low temperatures, compatible with rotary evaporators, vacuum freeze drying oven, etc.

Model : LTC-5020; LTC-5030; LTC-5040

Lift Head : 4.6 m
Compressor : 4P/ 5P/ 7P
Refrigerant : R404/ R22
Liquid Storage Capacity : 50 L
Bath Opening Diameter : 410 mm
Circulating Pump Flow Rate : 23 L/min
Temperature Range : -20 ℃–RT/ -30 ℃–RT/ -40 ℃–RT
Designed to efficiently circulate coolant in systems requiring precise temperature control at low temperatures, compatible with rotary evaporators, vacuum freeze drying oven, etc.

Model : LTC-4004

Cycle Mode : Closed cycle
Lift Head : 2.7/3.4 m (50/60 Hz)
Maximum Flow : 16/19 L/min (50/60 Hz)
Temperature Usage Range : -20 ℃–RT
Condition Liquid Temperature RT 20 ℃
Temperature Sensor : PT100 thermistor
Designed to efficiently circulate coolant in systems requiring precise temperature control at low temperatures, compatible with rotary evaporators, vacuum freeze drying oven, etc.

Model : FS-32I

Channel Qty. : 2–32 customizable
Volume Capacity : 0.1–9999.99 mL
Filling Volume : 0.1–100 mL
Volume Adjustment Resolution : 0.01 mL
The integrated filling system supports configurable channel counts ranging from 2 to 32, with full customization options available to accommodate diverse experimental and industrial production requirements.

Model : FS-32M

Channel Qty. : 2–32 customizable
Volume Capacity : 0.1–9999.99 mL
Filling Volume : 0.1–100 mL
Volume Adjustment Resolution : 0.01 mL
The dual control mode of offline and online operation makes it suitable for a wide range of laboratory and production scenarios.

Model : VP-D10T; VP-D20T; VP-D50T; VP-D80T

Pumping Speed (m³/h) : 10; 20; 52; 80
Rated power (Voltage) : 380/220
Frequency (Hz) : 50/60
Cooling method : Aircooling

Model : VP-D10H; VP-D15H; VP-D20H

Rotaryspeed(rpm) : 1500 rpm
hlet/Outlet cannector : KF25
Powersupply(w) : 550W; 750W
No ise level(dB(A) : 55 dbA

Model : VP-D10S; VP-D15S; VP-D20S

Rotaryspeed(rpm) : 1500 rpm
hlet/Outlet cannector : KF25
Powersupply(w) : 550W; 750W
No ise level(dB(A) : 55 dbA

Model : VP-D1A/VP-DH1A; VP-D2A; VP-D5A; VP-DP2A; VP-D12A; VP-DH2A; VP-D10A; VP-D8A; VP-D16A; VP-DH8A

Frequency conversion : Rated at 1400
Components : Wetted parts
Displacing valve : FFKM
Diaphragm : "Sandwich Configuraticn" PTFE

Model : VP-8TD; VP-16TD; VP-24TD; VP-30TD; VP-40TD; VP-60TD; VP-90TD

Partialultimate pressure without gas ballast(Pa) : 5x10⁻²; 4×10⁻²
Total ultimate pressure without gas ballast(Pa) : 1
Total ultimate pressure with gas ballast(Pa) : 6
Vapour allowed pressure(Pa) : 20; 25
