Model : MF-1-12; MF-2-12E; MF-6-12E; MF-9-12; MF-2-14; MF-4-14; MF-9-14; MF-16-14; MF-2-17; MF-4-17; MF-9-17; MF-16-17

Capacity (L) : 1 / 4.5 / 12 / 36 / 1 / 4.5 / 12 / 36/ 1 / 4.5 / 12 / 36
Max. Temperature : 1200 /1400 /1700 ℃
Temperature Rising Speed : 0-30 ℃/Min, adjustable (suggest ≤10 ℃/Min)
Chamber Material : Alumina ceramic fiber
Heating Mode : Three sides heating/Two sides heating/Two sides heating
Box-type muffle furnace is specifically designed equipment for sintering and melting analysis of metallic, non-metallic and other compound materials, used in laboratories of colleges and universities and so on.

Model : MF-1-12B; MF-2-12B; MF-6-12B; MF-9-12B; MF-2-14B ; MF-4-14B; MF-9-14B; MF-16-14B; MF-2-17B; MF-4-17B; MF-9-17B; MF-16-17B

Max Temperature : 1200 /1400 /1700 ℃
Temperature Sensor : K type (0-1200 ℃)/S type (0-1600 ℃)/B type (0-1820 ℃)
Heating Model : Three sides heating;/Two sides heating;/Two sides heating
Temperature Rising Speed : 0-20 ℃/Min, adjustable (suggest ≤10 ℃/Min)
Box-type atmosphere furnace is an ideal equipment for atmosphere-protected sintering and atmosphere restoration in universities, research institutes and industrial and mining enterprises.

Model : MF-10-7P

Thermal Couple : K type
Pre-Vacuum Degree : -0.1 MPa
Shaking Mode : Convolution
Flow Meter Range : 0.16–1.6 cubic meters/hour
Short-Term Maximum Temperature : 1100 ℃
Chamber Material : 310S high-temperature stainless steel
Designed for heating (sintering) products in a pre-vacuum atmosphere, and also for use without pre-vacuuming, using a protective gas washing furnace to heat products under an atmosphere.

Model : FF-12; FF-25

Rated Temperature : 1200 ℃
Furnace Body : High-insulation refractory bricks
Temperature Sensor : "K" type thermocouple
Electrical Requirement : 18 /40 kW Three-phase
Taking Cupel Quantity : 12×50/65 g; 25×50/65 g; 16×30/40/55 g; 42×30/40/55 g
It is mainly applied to heating and melting samples in pyrometallurgical assays.

Model : CF-50; CF-100

Electrical load: 5 AMPS
Rated Temperature : 1200 ℃
Temperature Control : K-Type Thermocouple
Electrical Requirement : 10.5/35 kW Three-phase
Taking Cupel Quantity : 50×6a/ 7a/ 7as, 100×6a/ 7a/ 7as
It is primarily used for refining ash in pyrometallurgical assays.

Model : RF-50

Temperature : 1000 ℃
Tray Material : 304 stainless steel
Consumption : 10.5 kW, Three-phase current.
Temperature Control : K-type thermocouples
Quantity : 6 pcs with a pitch of 125 mm
Ashing calcining can use for heating during processes such as quenching, annealing and tempering.

Model : IDO-70H; IDO-140H; IDO-270H

Capacity : 70 L/140 L/270 L
Temperature range : 50℃~250℃
Temperature uniformity : ≤ Max operating temperature ±3.5%
Timer(min) : 0-9999
