Model : ST-VGA50; ST-VGA80; ST-VGA100; ST-VG50; ST-VG80; ST-VG100; ST-VG120

Ambient Temperature: 5℃~40℃
Relative Humidity : ≤85%
Highest Working Pressure : 0.25Mpa
Atmospheric Pressure: 70kpa~106kpa
Power Supply : AC 220±22 V, 50±1 Hz
Note: Manufacturers and users should consider the impact of local atmospheric  pressure on sterilizer parameter settings when using sterilizers.

Model : ST-VG35; ST-VG50I; ST-VG75; ST-VG100I

Volume : 35L; 50L; 75L; 100L
Design Temperature : 139℃
Rated Working Pressure : 0.22MPa
Rated Working Temperature : 134℃
Professional grade self-control drying vertical pressure steam sterilizer ideal for all general medical and laboratory applications.

Model : ST-VB35; ST-VB50; ST-VB75; ST-VB100

Volume : 35L; 50L; 75L; 100L
Design Temperature : 139℃
Rated Working Pressure : 0.22MPa
Rated Working Temperature : 134℃
High-performance, easy-to-operate steriliser with a maximum sterilisation temperature of 135°C, suitable for protein modification.

Model : ST-VLA50; ST-VLA80; ST-VLA100; ST-VL50; ST-VL80I; ST-VL100; ST-VL120

Temperature (℃) : 121℃-134℃
Highest Working Pressure : 0.25Mpa
Temp.Accuracy : 0.5℃
Design Pressure : 0.28~0.3Mpa
ST-VLA series with drying function
Designed to meet today's ever-changing laboratory sterilisation needs, this autoclave is designed to sterilise solids and liquids quickly, safely and easily.

Model : ST-VPA50; ST-VPA80; ST-VPA100; ST-VP50; ST-VP80; ST-VP100; ST-VP120

Highest Working Pressure : 0.25Mpa
Temperature(℃) : 121℃~134℃
Temp.Accuracy : 0.5℃
Design Pressure : 0.28~0.3Mpa


Model : ST-V200L

Capacity : 200L
Control : Automatic Control
The Main Material : 304 Stainless steel
Sterilization Chamber Volume (DxH)(mm) : 500x1000
Large capacity vertical pressure steam autoclave with small footprint.

Model : ST-V35BS; ST-V50BS; ST-V75BS; ST-V100BS; ST-V120BS; ST-V150BS

Capacity (L) : 35; 50; 75; 100; 120; 150
Design Temperature : 139 °C
Rated Working Pressure : 0.22 MPa
Sterilization Temperature Setting Range : 116~134 °C
Sterilization Time Setting Range : 4-120 min
Note: Manufacturers and users should consider the impact of local atmospheric pressure on sterilizer parameter settings when using sterilizers.

Model : ST-B60PV; ST-B80PV

Capacity : 60L; 80L
Chamber Size(mm) : φ386x520; φ386x692
Designed Pressure : -0.1/0.3Mpa
Large capacity pulse vacuum autoclave with small footprint.

Model : ST-H60PV; ST-H80PV; ST-H100PV; ST-H150PV; ST-H200PV; ST-H300PV; ST-H450PV
Warranty : 2 Years
Drying Function : Yes
Single Negative Pressure Pulsation Time : 90 seconds
Standard Sterilization Cycle Time : 40 minutes, Fast Cycle
Drying Stage Working Pressure (Vacuum) : ≥ -85 kPa (Deep Vacuum)
The horizontal pulse vacuum autoclave provides more efficient vacuum degassing with precise control of temperature, pressure and time to ensure safe and effective sterilisation.

Model : ST-BA650PV; ST-BA800PV; ST-BA1000PV; ST-BA1200PV; ST-BA1500PV

Capacity(L) : 650 / 800 / 1000 / 1200 / 1500
Chamber Design Pressure : 0.3MPa
Generator Design Pressure : 1.0MPa
Design Temperaure : 150℃
Maximum Operating Temperature : 139℃
This vacuum autoclave needs to be used with an air compressor
