Optical Path : 0.4, 0.1, 0.04, 0.02 mm Volume Requirements : Ultra trace 0.3–2 μL Detection Wavelength Range : 190–850 nm Xenon Lamp Photometric Range : 185–2000 nm Wavelength Resolution : 2 nm (FWHM at Hg 254 nm)
It is designed for rapid and accurate quantification in genomics, proteomics, molecular biology, biotechnology, the pharmaceutical industry and life sciences research. It also includes a built-in fluorescence module.
The Microvolume UV-Vis Spectrophotometer is designed for the rapid and accurate quantification of microvolumes in genomics, proteomics, molecular biology, biotechnology, pharmaceuticals and life sciences research. The instrument also includes a built-in fluorescence module, capable of measuring fluorescence intensity, supporting Ion Sphere mode, and providing customizable options like excitation/emission light sources and fluorescence kinetics. Perfect for high-throughput labs and those requiring small sample volumes, it ensures accurate results with minimal sample waste.
Advantage:
1. Output port: It has 2 USB-A interfaces, 1 Type C interface, 1 HDMI, and 1 Ethernet port, which can be used to connect with various devices such as mice, keyboards, desktop computers, etc;
2. Equipped with a one click function to export scanned detection results spectra;
3. Can export various forms of detection reports;
4. Fluorescence detection range: 5 orders of magnitude;
5. Fluorescence detection has a custom standard curve module, which can be more freely compatible with more reagent kits and experimental methods;
6. Fluorescence detection has a kinetic module that can perform fluorescence kinetic detection and draw kinetic curves;
7. The colloidal gold module has a unique automatic peak detection function, which can automatically search for the characteristic wavelengths of colloidal gold with different particle sizes;
8. The standard curve has multiple fitting methods to meet diverse experimental needs;
Blue excitation at 430–495 nm, red excitation at 590–640nm
-
-
Emission Filter
Green emission 510–580 nm, red emission 660–725 nm
-
-
Detector
Photodiode (320–1100 nm)
-
-
Sample Flux
1 piece
-
-
Sample Dosage
1–20 μL
-
-
Tube Type
0.5 mL PCR tube
-
-
Tube Sampling Volume
≥100 μL
-
-
Warm-Up Time
No preheating required
-
-
Measurement Speed
3s/tube
-
-
Linear
R²≥0.995
-
-
Linear Range
5 orders of magnitude
-
-
Built in reagent calculator to calculate the required amount of dye and buffer solution for the working solution
-
-
Equipped with a fluorescence meter mode, it can directly measure the fluorescence intensity of the sample
-
-
Equipped with lon Sphere mode
-
-
Including fluorescence standard curve module, allowing for free selection of excitation and emission light sources, curve type, standard volume, and total reagent volume
-
-
Including fluorescence kinetics module, customizable delay time, interval time, and detection frequency for up to 5 stages.
-
-
Optional Function
Mixing Function
-
Optional
Optional
Print Function
Optional
Optional
Optional
Liquid Column Monitoring Function
Optional
Optional
Optional
Audit Tracking Function
Optional
Optional
Optional
External Size (W×D×H)
200×300×200 mm
Shipping Size (W×D×H)
360×290×330 mm
N.W/G.W.
3.5 / 4.5 kg
Application:
The Microvolume UV-Vis Spectrophotometer is designed for the rapid and accurate quantification of microvolumes in genomics, proteomics, molecular biology, biotechnology, pharmaceuticals and life sciences research. The instrument also includes a built-in fluorescence module, capable of measuring fluorescence intensity, supporting Ion Sphere mode, and providing customizable options like excitation/emission light sources and fluorescence kinetics. Perfect for high-throughput labs and those requiring small sample volumes, it ensures accurate results with minimal sample waste.
Advantage:
1. Output port: It has 2 USB-A interfaces, 1 Type C interface, 1 HDMI, and 1 Ethernet port, which can be used to connect with various devices such as mice, keyboards, desktop computers, etc;
2. Equipped with a one click function to export scanned detection results spectra;
3. Can export various forms of detection reports;
4. Fluorescence detection range: 5 orders of magnitude;
5. Fluorescence detection has a custom standard curve module, which can be more freely compatible with more reagent kits and experimental methods;
6. Fluorescence detection has a kinetic module that can perform fluorescence kinetic detection and draw kinetic curves;
7. The colloidal gold module has a unique automatic peak detection function, which can automatically search for the characteristic wavelengths of colloidal gold with different particle sizes;
8. The standard curve has multiple fitting methods to meet diverse experimental needs;
Blue excitation at 430–495 nm, red excitation at 590–640nm
-
-
Emission Filter
Green emission 510–580 nm, red emission 660–725 nm
-
-
Detector
Photodiode (320–1100 nm)
-
-
Sample Flux
1 piece
-
-
Sample Dosage
1–20 μL
-
-
Tube Type
0.5 mL PCR tube
-
-
Tube Sampling Volume
≥100 μL
-
-
Warm-Up Time
No preheating required
-
-
Measurement Speed
3s/tube
-
-
Linear
R²≥0.995
-
-
Linear Range
5 orders of magnitude
-
-
Built in reagent calculator to calculate the required amount of dye and buffer solution for the working solution
-
-
Equipped with a fluorescence meter mode, it can directly measure the fluorescence intensity of the sample
-
-
Equipped with lon Sphere mode
-
-
Including fluorescence standard curve module, allowing for free selection of excitation and emission light sources, curve type, standard volume, and total reagent volume
-
-
Including fluorescence kinetics module, customizable delay time, interval time, and detection frequency for up to 5 stages.
As a professional lab and medical equipment manufacturer, Scitek Global is certified by ISO 9001, ISO 13485, ISO 45001 and ISO 14001. Almost all our products are certified by ETL, CE and FDA .
Scitek Global looks forward to establishing cooperation with more distributors all over the world, and working together to create greater customer value.
