Wavelength Resolution : 2 nm Monitor : 8-inch touch screen Detection Wavelength Range : 190–910 nm Volume Requirements : Ultra trace 0.3–2 μL Detection Time : Less than 3 seconds Optical Path : Ultra micro mode 1, 0.2, 0.1, 0.03, 0.02 mm Designed for the rapid and accurate quantification in genomics, proteomics, molecular biology, biotechnology, pharmaceuticals and life sciences research. It also includes a built-in fluorescence module.
The Microvolume UV-Vis Spectrophotometer is designed for the rapid and accurate quantification of microvolumes in genomics, proteomics, molecular biology, biotechnology, pharmaceuticals and life sciences research. The instrument also includes a built-in fluorescence module, capable of measuring fluorescence intensity, supporting Ion Sphere mode, and providing customizable options like excitation/emission light sources and fluorescence kinetics.
3. Supported languages: Chinese, English and other multiple languages
4. Supports USB data output, can be connected to Ethernet, Bluetooth and WI-FI
5. Data output port: It has 2 USB-A interfaces, 1 Type C interface, 1 HDMI, and 1 Ethernet port, which can be used to connect with various devices such as mice, keyboards, and desktop computers
6. Data storage method: The measurement results are automatically saved in spreadsheet mode and can be exported via USB
Blue excitation at 430–495 nm, red excitation at 590-640 nm
-
-
Emission Filter
Green emission 510–580 nm, red emission 660–725 nm
-
-
Detector
Photodiode (320–1100 nm)
-
-
Sample Flux
1 piece
-
-
Sample Dosage
1–20 μL
-
-
Tube Type
0.5 mL PCR tube
-
-
Tube Sampling Volume
≥100 μL
-
-
Warm-Up Time
No preheating required
-
-
Measurement Speed
3 s/tube
-
-
Linear
R² ≥0.995
-
-
Linear Range
5 orders of magnitude
-
-
Built in reagent calculator to calculate the required amount of dye and buffer solution for the working solution
-
-
Equipped with a fluorescence meter mode, it can directly measure the fluorescence intensity of the sample
-
-
Including lon Sphere mode
-
-
Including fluorescence standard curve module, allowing for free selection of excitation and emission light sources, curve type, standard volume, and total reagent volume
-
-
Including fluorescence kinetics module, customizable delay time, interval time, and detection frequency for up to 5 stages.
Optional Function
Mixing function
Optional
Optional
-
Print function
Optional
Optional
Optional
External Size (W×D×H)
200×300×200 mm
Shipping Size (W×D×H)
360×290×330 mm
N.W/G.W.
3.5/4.5 kg
Application:
The Microvolume UV-Vis Spectrophotometer is designed for the rapid and accurate quantification of microvolumes in genomics, proteomics, molecular biology, biotechnology, pharmaceuticals and life sciences research. The instrument also includes a built-in fluorescence module, capable of measuring fluorescence intensity, supporting Ion Sphere mode, and providing customizable options like excitation/emission light sources and fluorescence kinetics.
3. Supported languages: Chinese, English and other multiple languages
4. Supports USB data output, can be connected to Ethernet, Bluetooth and WI-FI
5. Data output port: It has 2 USB-A interfaces, 1 Type C interface, 1 HDMI, and 1 Ethernet port, which can be used to connect with various devices such as mice, keyboards, and desktop computers
6. Data storage method: The measurement results are automatically saved in spreadsheet mode and can be exported via USB
Blue excitation at 430–495 nm, red excitation at 590-640 nm
-
-
Emission Filter
Green emission 510–580 nm, red emission 660–725 nm
-
-
Detector
Photodiode (320–1100 nm)
-
-
Sample Flux
1 piece
-
-
Sample Dosage
1–20 μL
-
-
Tube Type
0.5 mL PCR tube
-
-
Tube Sampling Volume
≥100 μL
-
-
Warm-Up Time
No preheating required
-
-
Measurement Speed
3 s/tube
-
-
Linear
R² ≥0.995
-
-
Linear Range
5 orders of magnitude
-
-
Built in reagent calculator to calculate the required amount of dye and buffer solution for the working solution
-
-
Equipped with a fluorescence meter mode, it can directly measure the fluorescence intensity of the sample
-
-
Including lon Sphere mode
-
-
Including fluorescence standard curve module, allowing for free selection of excitation and emission light sources, curve type, standard volume, and total reagent volume
-
-
Including fluorescence kinetics module, customizable delay time, interval time, and detection frequency for up to 5 stages.
