Aesthetic and ergonomic, our product boasts an elegant design that seamlessly blends style with functionality.
Featuring an auto-calibration function, ensuring precise and hassle-free measurements.
Complies with the stringent first-grade requirements of JJG696, ensuring top-tier performance.
Ample storage capacity capable of saving over 35,000 data entries for extensive data management.
Convenient auto-power-off option, adjustable within a range of 30-120 seconds based on user preferences.
Adheres to international standards including ISO2813, ASTM523, GB/T9754, ensuring reliability and accuracy.
Equipped with PC software, facilitating quality reporting and offering additional extended functions.
Designed with multiple working modes and versatile functions, catering to the diverse requirements of our customers.
Model | CM-P268 Tri-angle Gloss Meter |
---|---|
Measuring Angle | 20° 60° 85° |
Measuring Area | 20°: 0-2000GU |
60°: 0-1000GU | |
85°: 0-160GU | |
Division Value | 0.1GU |
Measuring Modes | Basic mode; Statistic mode; Continuous mode; QC mode |
Measuring Time | 0.5S |
Repeatability | 0~100GU : ±0.2GU; 100~2000GU : ±0.2%GU |
Accurate | Conform with JJG696 first grade requirements of gloss meter |
Auto Power-off Time | Within 30s-120s |
Long-time Calibration | Automatically check and made the calibration |
Language | Chinese & English |
Storage | 35000 (Basic mode & Statistic mode : 1500; Continuous mode : 10000; QC mode: 10000) |
Display | 2.3 inch white and black screen |
Size | 160x52x84mm |
Weight | About 300g |
Power Supply | 1pc dry-cell battery (can measure 10000 times) or use USB Charge |
Interface | USB & Bluetooth 2.1 version |
PC Software | GQC6 QC software can printing testing report and with more extended functions |
Operation Temperature Range | 0-40℃ (32-104° F) |
Storage Temperature Range | -20-50℃ (-4-122° F) |
Humidity Range | < 85% RH, without condensation |
Standard Accessories | USB cable, user manual, calibration plate, QC software |
Optional Accessories | Miniature printer |
Notification: The technical parameter is only for reference |
