| Optical Geometry | D/8(diffused illumination, 8-degree viewing angle) |
| Specular Component | SCI Including the specular reflection of light |
| Meet The Criteria | CIE NO.15, GB/T 3978, GB 2893, GB/T 18833, ISO7724-1, ASTME1164, DIN5033 Teil7 |
| Repeatability | △E*ab≤0.05 |
| Inter-instrument Error | △E*ab≤0.4 |
| Displayed Accuracy | 0.01 |
| Measuring/Illuminating Aperture | Dual Apertures:φ8MM/φ10mm platform+φ8MM/φ10mm tip |
| Measurement Indicators | Spectral eflectivity, CIE-Lab, CIE-LCh, HunteLab, CIE-Luv, XYZ, Yxy, RGB, chromatic aberration (△E*ab, △E*CMC, △E*94, △E*00), whiteness (ASTM E313-00, ASTM E313-73, CIE/ISO, AATCC, Hunter, Taube Berger Stensby), yellows (ASTM D1925, ASTME313-00, ASTM E313-73), staining fastness, color-changing fastness,etc. (some of the indicators were achieved by PC) |
| Illuminant | D65,A,C,D50,F2,F7,F11 |
| Displayed Data | Samples Chromaticity Values, Color Difference Values/Graph, PASS/FAIL Result, Color Simulation, Color Offset |
| Light Source | Combined full spectrum LED light source |
| Locating Method | Stability film,visual |
| Calibration | Intelligent automatic calibration(Contact Type) |
| Observe Angle | 2°,10° |
| Integrating Sphere Size | 40mm |
| Spectrophotometric Mode | Flat Grating |
| Sensors | Large-area silicon photodiode array(double-row 20 group) |
| Wavelength Interval | 10nm |
| Wavelength Range | 400-700mm |
| Measured Reflectance Range | 0-200% |
| Reflectivity resolution | 0.01% |
| Measurement Mode | Single Measurement, Average Measurement(2-99times) |
| Measuring Time | About 1s |
| Weight | About 435g(Calibration block not included) |
| Battery | Li-ion battery, 8500 measurements within 8 hours |
| Illuminant Life Span | 10 years, more than 1.5 million times measurements |
| Display | 3.5-inch TFT color LCD,Capacitive Touch Screen |
| Data Port | USB |
| Data Shorage | Standard 500 Pcs,Sample 10000 Pcs,Mass storage on PC side |
| Software Support | Windows |
| Language | Simplified Chinese, English, Traditional Chinese |
| Operating Environment | 0~40℃, 0~85%RH(no condensing), Altitude<2000m |
| Storage Environment | -20~50℃,0~85%RH(no condensing) |
| Standard Accessory | Power Adapter, USB Cable, User Guide, PC Software (Download from office website), White and Black Calibration Cavity, Protective Cover, Wrist strap, 8mm flat aperture, 4mm tip aperture |
| Optional Accessory | USB Micro Printer,Powde Test Box |
| External Size(WxDxH)(mm) | 114×70×208 |
| Shipping Size(WxDxH)(mm) | 360x320x160 |
| N.WG.W. (kg) | 0.46/4 |
