CM-P60CP portable colorimeter is widely used in plastic, electronic, paint, ink, textile, garment, printing and dyeing, food, medical, cosmetic, industries, scientific research institutes, schools and laboratories. It can precisely measure kinds of color indexes in various color spaces and easy to use with powerful functions. The portable colorimeter is equipped with high-end color management software which can be connected to PC to achieve more extension functions.
Easily measure concave surfaces with the option to switch between 8mm and 4mm measuring apertures.
Achieve heightened measurement stability and precision with a Delta E ab value of less than 0.03.
Experience versatility with a broader range of color spaces, diverse color indexes, and extensive applications.
Benefit from dual locating methods: illuminating locating and cross locating.
Operate seamlessly with the inclusion of a high-capacity rechargeable Li-ion battery.
Simplify operations with built-in white plate parameters and a physical white calibration board.
Ensure enhanced measurement stability through the new integrating sphere optical path design.
Obtain measurement data that meets national metrology authentication standards.
Model | CM-P60CP |
---|---|
Illuminating/Viewing Geometry | 8/d |
Light Source | LED Light |
Sensor | Silicon photodiode array |
Measuring Aperture | Φ8mmflat aperture; Φ4mmtip aperture |
Color Space | CE LAB, XYZ, LCh, CIE RGB, CIE LUV |
Color Difference Formula | ΔE* ab, ΔE(h), ΔE* uv, ΔE* 94, ΔE* cmc (2:1), ΔE*cmc (1:1), ΔE* 00 |
Other Chromaticity Data | WI (E313, CI E, AATCC, Hunt er), YI (D1925, 313), Color Fastness, Staining Fastness, J PC79, BFD(1.5:1), FMCI I |
Observer | CI E 10° |
Illuminant | D65, A, C, D50, F2, F6, F7, F8, F10, F11, F12 |
Display Data | Colorimetric Value, Color Difference Value/Graph, PASS/FAIL Result, Color Offset, |
Measuring Time | 0.4s |
Repeatability | ΔE* ab 0. 03 (Average of 30 measurements of the standard white plate within 5s) |
Errors Between Each Instrument | Within Delta E*ab 0.2 |
Size | 205x67x80mm |
Packaging Size | 370x170x320mm |
Net/ Gross Weight | 1.5/2.5kg |
Battery | Rechargeable lithium-ion battery 3.7V @ 3200mAh |
Lamp Life | 5 years, more than 1.6 million measurements |
Screen | TFT 2.8 inch (16: 9) |
Interface | USB/ RS- 232 |
Storage | 100 Standards, 20000 Samples |
Operating Temperature | 0~40℃ (32~104°F) |
Storage Temperature | -20~50℃ (-4~122°F) |
PC Software | CQCS3 software |
Optional accessory | Miniature thermal printer, powder test box |
What is a colorimeter?
A colourimeter is a photosensitive instrument used to measure how light is absorbed and transmitted in a liquid sample.
Inaccurate or drifting measurement results
Possible causes:
Sensor contamination (dust, fingerprints or liquid residue)
Calibration failure or failure to use standard calibration tablets
Ambient light interference (bright light or UV effects)
Voltage instability due to low battery
Solution:
Wipe the sensor window with a special cleaning cloth
Recalibrate (use original standard white plate or calibration solution)
Measure under a stable light source, avoid direct light
Replace the battery or connect the power adapter
Failure to turn on or sudden shutdown
Possible causes:
Battery depleted or poor contact
Power button damaged or circuit failure
Device overheating protection triggered
Solution:
Check battery polarity and replace with new batteries
Try charging or using an external power source
Contact after-sales service to repair the circuit problem
Abnormal screen display (splash screen, flickering)
Possible causes:
Loose or damaged screen wires
Faulty motherboard or software error
Solution:
Restart the device and restore factory settings
Contact the manufacturer to repair the screen or motherboard
Poor repeatability (inconsistent results for multiple measurements of the same sample)
Possible causes:
Uneven sample or offset measurement position
Insufficient warm-up time
Aging of the sensor or decay of the light source
Solution:
Ensure that the sample is uniform (e.g. liquid is well mixed, solid surface is flat)
Warm up the device for 5~10 minutes before measurement
Contact the manufacturer to check the status of the sensor
Measured value out of range (Error message)
Possible causes:
Sample concentration is too high or color is out of range
Wrong measurement mode is selected
Solution:
Dilute the sample or change to a higher range model.
Check device settings (e.g. chromaticity space: Lab/RGB/HSV)
