| Optical geometry | D/8(diffuse illmination,8°direction reception)SCl measurement Comply with standar CIE No.15,GB/T 3978,GB 2893,GB/T 18833,ISO7724-1,ASTM E1164,DIN5033 Teil7 |
| Characteristics | Customized single measurement aperture for accurate color difference control in plastic and electronic, paint and ink, textile and garment printing and dyeing, printing, ceramics and other industries |
| Ntegrating sphere size | φ40mm |
| Light source | Combined full-spectrum LED light source |
| Spectroscopic method | Planar grating |
| Sensor | Silicon photodiode arrays(dual row 32 groups) |
| Wavelength range | 400~700nm |
| Wavelength interval | 10nm |
| Semiband Bandwidth | 10nm |
| Measurement range | L: 0~120 Reflectivity:the instrument can test the reflectivity at 3 specific wavelengths specifiedby the user(default 440nm, 550nm, 600nm) |
| Measurement aperture | Single aperture: φ8mm (φ4mm optional) |
| Focusing method | Fixed Focus |
| Specular component | SCI |
| Color space | CIE LAB, XYZ, Yxy, LCh |
| Color difference formula | △E*ab,△E*00 |
| Observer angle | 10° |
| lluminant | D65, A, F2(CWF) |
| Displayed data | Reflectivity (at 3 specific wavelengths specified by the user) chromaticity value,color difference value/graph, pass/fail result, color simulation, color offset |
| Display Accuracy | 0.01 |
| Measurement time | Approx.1.5s |
| Repeatability | Chromaticity value: MAV/SCl, △E*ab within 0.04 (When a white calibration plate is measured 30 times at 5 second intervals after white caibration) |
| Nter-instrument error | MAV/SCl, within △E*ab 0.35 (Average for 12 BCRA Series II color tiles) |
| Measurement method | Single measurement,average measurement(2~99 times) |
| Locating method | Stabilizer locating |
| Battery power | Lithium battery,6000 times in 8 hours |
| lluminant life span | 5 years,more than 3 million times measurements |
| Display | TFT true color 3.5inch, capacitive touch screen |
| Data port | USB, Bluetooth 5.0 |
| Data storage | 500 standard samples,1,0000 samples |
| Language | Simplified Chinese,English,Traditional Chinese |
| Operating temperature range | 0~40℃,0~85%RH(no condensation),altitude<2000m |
| Storage temperature range | -20~50℃,0~85%RH (no condensation) |
| Standard Accessories | Power adapter,data cable,manual,,black and white calibration box,protective cover,wrist strap,single aperture:φ 8mm(optional φ4mm)platform aperture |
| Optional Accessories | USB micro printer,powder test box,Bluetooth mcro printer |
| External Size(WxDxH)(mm) | 81x71x241 |
| Shipping Size(WxDxH)(mm) | 360x320x160 |
| N.WG.W. (kg) | 0.46/4 |
