Model | SP-UV6000I |
---|---|
Wavelength Range | 190-1100nm |
Spectral Bandwidth | 2nm |
Wavelength Accuracy | ±0.5nm |
Stray Light | 0.05% T @ 220 nm, 360 nm |
Wavelength Repeatability | ≤0.1nm |
Photometric Accuracy | ±0.2T(0-100%T) |
±0.002Abs(0-0.5Abs) | |
±0.004Abs(0.5-1.0Abs) | |
Photometric Repeatability | ≤0.05%6T(0-100%6T) |
0.001Abs(0-0.5Abs) | |
0.002Abs(0.5-1.0Abs) | |
Stability | ±0.001A/h@500nm |
Photometric Range | 0-200%T, -0.3-3.0A, 0-9999C |
Baseline Flatness | ±0.001A |
Noise | ±0.005A |
Display | 800x480 touch screen |
Data Output Port | USB |
Print Port | USB Port |
Light Source | Tungsten Lamp & Deuterium Lamp |
Power Requirements | AC220V/50Hz or 110v/60Hz |
Detector | Silicon Photodiode |
Size(W×D×H)(mm) | 460x380x180 |
Shipping Size(W×D×H)(mm) | 630x540x370 |
N.W./G.W. (kg) | 17/21 |
Adopting imported grating, lower stray light, and more accurate analysis.
7-inch touch screen, 32G memory, support for bluetooth connection network.
You can enter the calibration curve with the powerful data analysis function, the host built-in computer.
The optical system suspension design, the bottom plate deformation and external vibration on the optical system have no effect, greatly improving the stability of the visual system.
Powerful storage function, can directly connect the instrument to the printer for A4 format data and graphics printing.
With automatic power-on calibration and system positioning function, can repair the deviation caused by long-term use.
Data can be saved to U disk
