Application:
The electronic moisture-proof cabinet offers precise humidity control, and protect your valuable gears and samples from humidity,
mold, and corrosion. Find the perfect dry storage solution.
Advantage:
1. Sensor: Honeywell sensor, high precision and high stability, using a dedicated acquisition module design.
2. Temperature and Humidity Display: Ultra-high brightness LED digital display. Accurate and stable display
with a long service life. Humidity settings have a memory function, eliminating the need for resetting after power failure.
3. Power System: Uses a UL CE certified switching power supply system.
4. Cabinet Structure: Constructed from 1.2 mm high-quality steel plate, the cabinet features a high-strength structural design,
excellent load-bearing capacity, airtightness, and superior sealing performance.
5. Anti-static Model: The cabinet surface is coated with a special conductive powder coating, providing strong corrosion
resistance. Its surface resistivity is 10⁶-10⁹.
6. 360˚ Rotating Anti-static Casters with Brakes are installed at the bottom of the cabinet for easy movement and securing.
7. Cabinet Door Window: The door frame window is press-fitted with 40 mm high-strength tempered glass. The door handle uses
a flat-pressed, high-strength integrated handle lock with anti-theft function.
8. Load-bearing shelves: Perforated shelf surfaces accelerate air circulation within the cabinet. The reinforced shelf design
can withstand a uniformly distributed load of 100 kg per shelf. Shelf height can be adjusted to accommodate different item
heights, making storage more convenient and maximizing space utilization.
9. Main unit dehumidification principle: The electronic dehumidifier uses high-polymer environmentally friendly moisture-absorbing
materials and a shape memory alloy system for dehumidification. It features an intelligent microcomputer control system. Simply set the desired
humidity level, and the device will automatically operate. The main unit casing is made of high-temperature flame-retardant material, eliminating
safety hazards. It features automatic moisture absorption even in the event of a power outage, and can continue dehumidifying using chemical
moisture absorption compensation. Humidity increase will not exceed 10% within 24 hours. It does not generate moisture, heat, or drip water.
It is energy-efficient and has a long service life.
Specification:
Model MPC-160E MPC-240E MPC-320E MPC-435E MPC-540E MPC-728E MPC-870E MPC-1428E Humidity Control Range 0-10% (Other humidity ranges are customizable) Humidity Display Range 0%～99% RH Humidity Accuracy ±3% RH Temperature Display -9 ℃～99 ℃ Temperature Accuracy ±2 ℃ Manual Door Type Single Door Double Door Double Door Double Door Double Door Three Door Four Door Six Door Shelf 3 3 3 3 3 5 5 5 Color Black (Anti-static)/Grey External Size 450×450×1030 600×400×1265 900×450×1030 900×600×1030 600×750×1500 600×71×1920 900×600×1880 1200×710×1920 Package Size 550×550×1200 700×500×1480 1000×550×1200 1000×700×1200 700×800×1670 740×800×2060 1000×700×2060 1300×800×2060 N.W. (kg) 31 42 60 65 75 98 120 170 G.W. (kg) 43 66 80 86 101 120 145 208
