The shell of the product is made of high-quality steel plate, the surface of the electrostatic spraying paint film is firm, beautiful appearance, the studio is made of high-quality stainless steel plate, corrosion resistance, aging resistance, the inner liner around the arc transition.
Large touch screen, multiple groups of data on one screen display, 99*5 segment program control, with temperature curve, data storage function.
Frequency conversion compressor, cooling and heating balance control to ensure that the temperature fluctuation is small, more accurate temperature control.
Double-layer door structure, the inner door is made of high-quality tempered glass for sample observation, and the outer door is made of magnetic rubber strip for easy opening and closing and good sealing.
Intelligent frost function to ensure long-term frost-free operation of equipment, standard equipped with mechanical independent temperature limiter, double protection of experimental safety.
Built-in humidifying system, humidifying particles small humidity uniformity, low water consumption, with automatic water shortage alarm, one-click drainage and other functions.
Imported humidity sensor components, humidity automatic control, good stability and high precision. With compressor overheat protection, instrument failure protection, etc.
Model | ICB-80THP | ICB-150THP | ICB-250THP | ICB-350THP | ICB-460THP | |
---|---|---|---|---|---|---|
Capacity(L) | 80 | 150 | 250 | 350 | 460 | |
Circulation Mode | Forced convection | |||||
Size (WxDxH)(mm) | Internal | 400x400x500 | 400x500x750 | 500x550x910 | 600x600x1000 | 650x650x1100 |
External | 625x550x1065 | 600x660x1360 | 720x710x1570 | 800x760x1610 | 850x810x1715 | |
Temperature | Range (℃) | 0 ~ 65 | ||||
Fluctuation (℃) | High Temp.: ±0.5Low Temp.: ±1 | |||||
Resolution (℃) | 0.1 | |||||
Uniformity (℃) | ±1 | |||||
Sensor | PT100 | |||||
Humidity | Rang | 45%~95%RH | ||||
Stability | ±5%RH | |||||
Method | Internal | |||||
Sensor | ||||||
Controller | PID | |||||
Display | Large high definition LCD | |||||
Timer | 0~9999/99*5Segments (with timing wait function) | |||||
Material | Internal | Mirror stainless steel | ||||
External | Cold rolled steel electrostaticspraying exterior | |||||
Shelves (Standard/Max) | - | |||||
Test Hole | Φ43mm | |||||
External Socket | Universal socket(one) | |||||
Refrigerant | R134a (CFC free) | |||||
Defrosting Mode | Automatic | |||||
Safety Device | Over temperature, over humidity, water shortage alarm | |||||
Electricity | Voltage /Frequency | AC 220/110V, 50/60Hz | ||||
Consumption (W) | 600 | 800 | 1000 | 1200 | 1400 | |
G.W. (kg) | 61 | 88 | 112 | 139 | 168 | |
Shipping Size (WxDxH)(mm) | 690x620x1150 | 770x735x1520 | 820x800x1660 | 870x860x1800 | 990x1040x1970 | |
Standard | USB port for storing and exporting data | |||||
Optional | 485 interface, printer and spare shelf |
