| Principle | Electrical impedance for counting and SFT method for hemoglobin |
| Test parameters | WBC, LYM#, MID#, GRA#, LYM%, MID%, GRA%, RBC, HGB, HCT, MCV, MCH, MCHC, RDW-CV, RDW-SD, PLT, MPV, PDW, PCT, P-LCR, and 3 Histograms for WBC, RBC and PLT |
| Sample quantity | 9μL venous blood, 20μL pre-dilution blood |
| Sample Pre-dilution | Internal diluter, add 1ml dilutent automatically by the needle; no need to add diluent manually, to avoid error and make the operation more convenient and standard. |
| Working model | Dual-channel testing |
| Aperture | WBC: 80μm RBC/PLT: 50μm |
| Throughput | Automatic sampling, 60 samples per hour |
| Results storage | Storage of 10,000 patients’ results (including histogram). It is more convenient to manage and review historical data. |
| Reference value setting | For general use, male, female, children, newborns. |
| Calibration | Manual and automatic calibration |
| QC | Comprehensive QC program, forming and printing the histogram automatically. |
| Performance index | Precision (CV) linear range |
| WBC≤4.0% 1.0×109/L～99.9×109/L |
| RBC≤2.0% 0.30×1012/L～7.00×1012/L |
| HGB≤2.0% 20～240g/l |
| PLT≤8.0% 20～999×109/L |
| MCV≤3.0% |
| Test reagent | Diluent: 20L |
| Lyse: 500ml |
| Cleanser: 1L/5L |
| Maintenance reagent | Concentrated Cleanser: 50ml |
| Boot check | Self check for hardware, alarm for disorder |
| Clog-removal | Real time monitor, high ignition, soak, flush and back flush |
| Classification | Floating landmark technique |
| Mainframe control | ARM Intelligent micro-processing technology and high-performance document-management, display and print-processing. |
| Data analysis | Intelligent pulse formulation techniques |
| Structural features | Separate module design |
| Display | 10.4″ large color LCD displays all parameters and histograms simultaneously |
| Language | English, Chinese |
| Print | Internal thermal printer or USB port universal printer (matching) |
| Output | 3USB port, 1parallel printer port, 2 RS232 port |
| Power Supply | Temperature: 15-30℃; Humidity: ≤80%; Atmospheric pressure: 70Kpa-106Kpa |
| Power supply: AC220V, 50Hz |
| Temperature | 15-30℃; Humidity |
| Power supply | AC220V, 50Hz |
| Sizes(W×D×H)(mm) | 325x370x545 |
| Shipping size(W×D×H)(mm) | 650x450x600 |
| N.W./G.W. (kg) | 15/30 |
