| Basic parameters | Throughput | 60T/H |
| Test parameters | 29 Parameters: WBC, Lym%, Mon%, Neu%, Bas%, Eos%, Lym#,Mon#, Neu#, Eos#, Bas#, RBC, HGB, HCT, MCV, MCH, MCHC, RDW-CV, RDW-SD, PLT, MPV, PDW, PCT, P-LCR, P-LCC, LIC%, LIC#, ALY%, ALY# |
| Histogram | 2 Scatter plots, 2 Histograms (including RBC, PLT histograms) |
| Principle technology | Triangular laser scattering and sheath flow methods are used to detect white blood cells, impedance method is used to detect red blood cells and platelets, cyanide-free method is used to detect hemoglobin, and immune scattering turbidimetry is used to detect specific protein concentrations. |
| Aisle | 4 |
| Gemstone hole diameter | RBC/PLT Gem Hole Diameter: 70 um |
| Analysis Methods | CBC, CBC+DIFF, HGB, RBC, WBC |
| HGB lamp wavelength | LED light wavelength 530 nm |
| Sample volume | Whole blood mode: 20ul, pre-diluted mode: 20ul |
| Species of Animals | Dog, Cat, Rabbit, Cattle, Horse, Sheep, Deer, Monkey, Rat, Pig, Ferret, Camel, Tiger, Dolphin, Mouse, Panda |
| software | Calibration | Manual, automatic and fresh blood calibration |
| Counting Mode | Whole blood, capillary whole blood, pre-diluted |
| Print | Automatic printing, manual printing |
| LISsystem | support LIS |
| Reagent | Reagent | Standard: diluent: 20L, DIFF Lyse: 500ml, LH Lyse: 100mL |
| Enhence cleaner | PB cleaner 50ml |
| Specification | Input | 10.4 inch touch screen, keyboard and mouse |
| Output | Built-in printer, supports external printer |
| Printing paper | 57×35 mm |
| Communication | 2 USB ports, 1 Ethernet port |
| Storage | 100,000 results |
| Blockage Clearance | High pressure, high pressure washing |
| Sizes(W×D×H) (mm) | 350x450x430 |
| Shipping Size (W×D×H)(mm) | 570x450x710 |
| N.W./G.W. (kg) | 28/36 |
| Others | Operating temperature | 10-30 °C |
| Power supply | 100~240 AC, 50/60 Hz, 200VA |
| Relative humidity | ≤85% |
| Atmospheric pressure | 70.0-106.0kPa |
| Performance | Carryover rate | Parameters | CV |
| WBC | ≤ 0.5% |
| RBC | ≤ 0.5% |
| HGB | ≤ 0.6% |
| PLT | ≤ 1.0% |
| Blank | Parameters | Background value |
| WBC | ≤ 0.2×109/L |
| RBC | ≤ 0.02×1012/L |
| HGB | ≤ 1 g/L |
| HCT | ≤ 0.5% |
| PLT | ≤10×109/L |
| Accuracy | Project | Whole blood sample CV (CV/absolute deviation d) | Pre-diluted sample CV (CV/absolute deviation d) | Measuring range |
| WBC | ≤2.0% | ≤4.0％ | (4.00~15.00)*109/L |
| RBC | ≤1.5% | ≤2.0% | (3.50~6.00)*1012/L |
| HGB | ≤1.5% | ≤2.0% | (110~180)g/L |
| PLT | ≤4.0% | ≤8.0% | (150~500)*109/L |
| Linear | Project | Linear range | Linearity deviation (whole blood mode) |
| WBC | (0.00~300.00)*109/L | ±5％ |
| RBC | (0.00~8.00)*1012/L | ±5％ |
| HGB | (0~250)g/L | ±2％ |
| PLT | (0~1000)*109/L | ±8％ |
