Humanity design, Polished stainless-steel chamber, semicircular arcs at corners for easy cleaning, and the space between the shelves in the chamber is adjustable.
Two-layer stacking available, facilitating the full utilization of laboratory space.
Faster CO2 concentration Restoration Speed.
Imported infrared sensor can keep CO2 concentration stability and uniformity when door open frequently.
Microorganism filter at inlet provides 99.99% filtration of bacteria and dust (Ф<0.3μm) and supplies pure CO2 into the incubator.
The speed of the circulating fan can be automatically controlled. When the temperature inside the box is at a constant temperature, the speed will decrease and the circulating wind speed will be adjusted to a suitable speed for cell growth, avoiding sample evaporation caused by excessive air volume during the experiment.
Door temperature controller prevents dewfall on glass door of incubator effectively.
Safety function: Independent audible and visible temperature-limiting alarm system ensures experiments run safely.(Optionals)
Alarm function for temperature difference, CO2 over concentration and concentration difference,door open time.
UV sterilization system: The ultraviolet sterilization lamp is located at the top and rear of the incubator, which can regularly disinfect the inside of the incubator and effectively kill floating bacteria in the circulating air and humidification tray steam inside the incubator, thereby effectively preventing contamination during cell culture.
Model | ICB-CA50(UV) ICB-CA80(UV) | ICB-CA150(UV) ICB-CA190(UV) | ICB-CA240(UV) | ICB-CW30(UV) | ICB-CW80(UV) | ICB-CW180(UV) |
---|---|---|---|---|---|---|
Capacity(L) | 50/80 | 150/190 | 240 | 30 | 80 | 180 |
Internal Size (W×D×H)(mm) | 400×350×350 400×450×500 | 480×530×610 520×530×690 | 600×630×670 | 290×290×310 | 400×400×500 | 500×500×650 |
External Size (W×D×H)(mm) | 580×450×540 590×657×870 | 670×710×950 708×710×1030 | 788×837×940 | 440×410×544 | 550×520×764 | 650×615×914 |
Heating method | Air jacket | Water jacket | ||||
Temperature fluctuation | ±0.2℃ | ±0.1℃ | ||||
Temperature control range | RT+5~55℃ | |||||
Working environment temperature | +5~30℃ | |||||
CO2 control range | 0~20% | |||||
CO2 control accuracy | ±0.1% (infrared sensor) | |||||
CO2 recovery time | (Recovery to 5% in 30 seconds)≤ 3 minutes | |||||
Temperature recovery | (Return to 37℃ in 30 seconds)≤ 8 minutes | |||||
Relative humidity | Natural evaporation ≥ 90% (no display) | |||||
Disinfection method | UV disinfection | |||||
Power Supply | AC 220/110V, 50/60Hz | |||||
Shelves (standard) | 2pcs | 3pcs | 3pcs | 2pcs | 2pcs | 3pcs |
Input power | 450W/500W | 750W | 950W | 250W | 680W | 950W |
N.W./G.W. (kg) | 59/79 | 83/126 | 95/148 | 50/65 | 55/90 | 68/125 |
64/98 | 85/134 | |||||
Shipping Size(WxDxH)(mm) | 830×800×980 740×700×1040 | 830×840×1250 830×840×1250 | 930×910×1220 | 560×800×540 | 700×670×1010 | 830×780×1070 |
Optionals | RS485 Connector: Easy to download and save all the data via RS485 into computer,and identify problems in time. CO2pressure releasing valve Embedded printer HEPA filter | RS485 Connector: Easy to download and save all the data via RS485 into computer,and identify problems in time. CO2pressure releasing valve Embedded printer HEPA filter |
