Application:
It is widely used in plant growth research, photobiology experiments, and scientific research, teaching and other departments.
It provides your samples with the most ideal growth environment, ensuring high reproducibility and accuracy of experimental data.
Advantages:
1. Double-door structure, the inner door is made of high-quality tempered glass, observation of samples easily.
2. A controller is installed on the door, and with the 7.0-inch color LCD touch screen.
3. The lighting intensity is adjustable in multiple levels, and it allows for free combination programming and operation
of 99 segments of temperature and illuminance parameters.
4. With the functions of data storage, export via a USB flash drive and scheduled power on/off.
5. Top lighting design with full-spectrum LED light sources. It is characterized by high illuminance, low heat radiation,
and an extremely long service life.
6. Equipped with an under-temperature protection function and an independent digital display high-precision
over-temperature limiter.
7. Once the temperature exceeds the limit, the heating output will be automatically cut off to ensure the safety
of samples and the equipment.
8. It uses a variable-frequency compressor, which offers advantages such as energy conservation, low noise, and no frosting.
Specifications:
| Model | ICB-R150L | ICB-R250L | ICB-R350L | ICB-R460L | |
| Capacity (L) | 150 | 250 | 350 | 460 | |
| Circulation Mode | Forced convection | ||||
| Internal Size (W×D×H) (mm) | 405×500×755 | 505×545×915 | 585×600×1050 | 650×650×1110 | |
| External Size (W×D×H) (mm) | 600×650×1350 | 700×705×1550 | 780×750×1605 | 845×805×1710 | |
| Display | 7 inch LCD touch screen | ||||
| Temperature Range | With Light: 10~65 °C; Without Light: 0~65 °C; | ||||
| Temperature Resolution | 0.1 °C | ||||
| Temperature Fluctuation | ±1 °C (The experimental condition is no-load, with an ambient temperature of 20 °C and a humidity of 50%RH) | ||||
| Sensor | PT100 | ||||
| Illuminance (lx) | 0~45000 (supports the input of illuminance) | ||||
| Illumination Control | 5-level relative illuminance control | ||||
| Light Source | 4-layer top-mounted LED illumination | ||||
| Controller | PID | ||||
| Timer | Each segment is 0~999 mins (99×5 segments program) | ||||
| Material | Internal | 304 mirror stainless steel | |||
| External | Electrostatic spraying of galvanized sheet | ||||
| Shelves | 4 | ||||
| Shelf Loading Capacity | 15 kg | ||||
| Refrigerant | R134A (CFC free) | ||||
