Sealing Speed : 10±0.5 m/min Width of Seal Pattern : 12 mm Sealing Margin Distance : 0~35 mm adjustable Temperature Control Error : ≤±1% The automatic sealing machine SM-A102TR ensures airtight, tamper-proof seals for bags and pouches. Boost your packaging line's efficiency. Now the best sealing machine for sale at cost price.
1. 7 "color LCD touch screen, graphical operation interface, display and print switching between Chinese and English, keyboard input control, built-in clock and parameters that can be set and have automatic storage function.
2. A positive (descending) sealing counter, it can achieve counting of sealing quantities within 0~9999.
3. Rapid heating and auxiliary cooling design: equipped with a microcomputer controlled heating and cooling structure.
4. Computer intelligent temperature control design, working temperature can be set arbitrarily between 60~220 ℃, temperature control accuracy ≤+1 ℃.
5. When the sealing temperature exceeds the set working temperature range by+4 ℃, the machine will automatically stop working, effectively ensuring the quality of sealing and the safe operation of the equipment.
6. Automatic fault alarm indication, which can achieve automatic detection of the working process.
7. Adjustable standby time and standby temperature, intelligent standby recovery, can quickly restore to working temperature, reducing waiting time.
8. The device comes with the function of running identification sealing and printing, which meets the packaging requirements of Part 5.7.10 of the second part of the health industry standard WS310.2-2016 of the People's Republic of China.
9. Comes with a sealing machine for English printing systems, with a built-in printer for clear printing and easy and fast settings for printing. The font width can be adjusted, making it flexible, convenient, and fast.
10. The system will provide a printing width value based on the selected printing content, automatically calculate the minimum bag width for printing, and help the operator determine the number of items before printing to select the appropriate packaging bag, achieving a reminder before sealing when the packaging bag width is insufficient.
Automatic Sealing Machine Specification:
Model
SM-A102TR
Sealing Speed
10±0.5 m/min
Width of Seal Pattern
12 mm
Sealing Margin Distance
0~35 mm adjustable
Temperature Control Error
≤±1%
AC Power Supply
3.2 A
Consumption
500 W
External Size (W×D×H)
560×260×220 mm
Package Size (W×D×H)
780×310×360 mm
G.W.
19 / 18 kg
Automatic Sealing Machine Feature:
1. 7 "color LCD touch screen, graphical operation interface, display and print switching between Chinese and English, keyboard input control, built-in clock and parameters that can be set and have automatic storage function.
2. A positive (descending) sealing counter, it can achieve counting of sealing quantities within 0~9999.
3. Rapid heating and auxiliary cooling design: equipped with a microcomputer controlled heating and cooling structure.
4. Computer intelligent temperature control design, working temperature can be set arbitrarily between 60~220 ℃, temperature control accuracy ≤+1 ℃.
5. When the sealing temperature exceeds the set working temperature range by+4 ℃, the machine will automatically stop working, effectively ensuring the quality of sealing and the safe operation of the equipment.
6. Automatic fault alarm indication, which can achieve automatic detection of the working process.
7. Adjustable standby time and standby temperature, intelligent standby recovery, can quickly restore to working temperature, reducing waiting time.
8. The device comes with the function of running identification sealing and printing, which meets the packaging requirements of Part 5.7.10 of the second part of the health industry standard WS310.2-2016 of the People's Republic of China.
9. Comes with a sealing machine for English printing systems, with a built-in printer for clear printing and easy and fast settings for printing. The font width can be adjusted, making it flexible, convenient, and fast.
10. The system will provide a printing width value based on the selected printing content, automatically calculate the minimum bag width for printing, and help the operator determine the number of items before printing to select the appropriate packaging bag, achieving a reminder before sealing when the packaging bag width is insufficient.
