| Measurement | Abdomen, Gynecology, Subcutaneous tissue, Small organ, etc. |
| Scanning Method | Convex/Linear/Micro-convex |
| Display Mode | B,B+B,4B,B+M,M,PW |
| Probe port | 1(Standard Configuration);
With automatic identification function to support a variety of probe work. |
| Display Screen | 15 inch LED medical display, able to reverse it above 160 degree. |
| Optional Probe Detail | 3.5MHz convex array probe | 3.5MHz, 4.0MHz, 4.3MHz, 5.0MHz;
Depth range: 90-250mm |
| 6.5MHz transvaginal array probe | 5.0MHz, 6.0MHz, 7.0MHz, 8.0MHz;
Depth range: 50-125mm |
| 7.5MHz linear array probe | 7.5MHz, 8.6MHz,10MHz, 12MHz;
Depth range: 40-90mm |
| 6.0MHz micro-convex array probe | 5.5MHz, 6.0MHz, 6.7MHz, 7.5MHz;
Depth range: 70-145mm |
| Harmonic Frequency Scope | 3.5MHz convex array probe | H3.5MHz, H4.0MHz, H4.3MHz, H4.4MHz, H4.6MHz; |
| 6.5MHz transvaginal array probe | 5.0MHz, 6.0MHz, 7.0MHz, 8.0MHz; |
| 7.5MHz linear array probe | H8.0MHz, H8.6MHz, H9.2MHz, H10MHz; |
| 6.0MHz micro-convex array probe | H5.5MHz, H5.7MHz, H6.0M, H6.5MHz; |
| System language | Chinese/English/Russian |
| Battery | Built-in lithium battery with 18650 international standard cell,
With Battery indicator and charging indicator |
| Interface | LAN; VGA; 2 USB; DICOM |
| The 2D-dimensional imaging mode: |
| Playback Frame | ≥1500 frame |
| Focus | 4, 30 levels, adjustable |
| Position Marker | 105 kinds |
| Adjustable Scanning Range | 7.5: 79-100%;
3.5: 46-60%;
6.0: 68-90% |
| Mode | More than 12 examination modes available |
| Storage | Hard disk storage or USB flash disk storage |
| Dynamic Range | 64-192, Step 2, 65 Levels visible and adjustable Cyclically |
| Gain | 2-100, step 2 |
| Pseudo Color | 8 kinds |
| Frame Correlation | 7 level is invisble and adjustable |
| Line Correlation | 5 level is invisble and adjustable |
| Line Density | 2 level is invisble and adjustable |
| Harmonic Wave | 2 level is invisble and adjustable |
| Data Output | Able to connect with laser/inkjet printer and other auxiliary equipment such as code scanner |
| Net Weight | 6.7KG |
