| Measurement | Abdominal; Urology; Gynecology; Heart; Obstetric; Small organs; Pediatric |
| Probe Details | 3.5 MHz Convex array probe | 2.0 MHz / 3.0 MHz / 3.5 MHz / 5.0 MHz /, adjustable (depth adjustment: level 19 or higher, the adjusting range 50-240mm) |
| 7.5 MHz Linear array probe | 5.0 MHz / 7.5 MHz / 8.0 MHz / 9.0 MHz, adjustable. (depth adjustment: level 5 or higher, the adjusting range 50-100mm) |
| 6.5 MHz Cavity probe | 4.0 MHz / 5.5 MHz / 6.5 MHz / 9.0 MHz, adjustable. (depth adjustment: level 7 or higher, the adjusting range 50-120mm) |
| Operating System | ARM, stable, simple, powerful |
| Display Mode | B, B+B, B+M, M, 4B; |
| Probe Port | 2, it can be selected the inspection position |
| Display | 12.1 inch 1024*768 resolution HIGH-DEFINITION LED LCD screen |
| System Language | Chinese and English |
| Interface | VGA port*1, RS232 port*1, USB port*2 |
| External Size(mm) | 290x300x65 |
| Package Size(mm) | - |
| N.W./G.W. (kg) | - |
| 2D imaging mode |
| Gain | 0-100, step 1, can be adjusted visually |
| TGC | 8 segments are adjustable |
| Dynamic Range | 0-120 dB |
| Scanning Angle | 80-100 |
| Focus | Adjustable, with 4 focal points |
| Frame Correlation | 4-100, step 0.5 |
| Spot Suppression | 0-50 |
| Ultrasonic Power | 40-100, step 4 |
| Magnification | 1-16 |
| Contrast | 1-9 |
| Brightness | 1-9 |
| Gamma Correction | 1-9 |
| Gray Scale Mapping | 1-19 |
| Position Marker | ≥109, support position indicator |
| Pseudo Color | 10 kinds |
| M Mode Scanning Speed | 1-63 |
| Support Time Setting | Date time, date format, time format, etc |
| Image Storage | BMP |
| Movie Playback | 256 |
| Notes | Support in upper and lower case in English |
