| Scanning Mode | Convex matrix / Linear array / Micro convex |
Measurement
| B; GYN,Thyroid,URO,Kidney,Cardiac,OB1,OB2 measurement. |
| Probe Port | Standard configuration: 1 probe ports
(Optional docking station for 2 probe ports) |
| Display Mode | B, B + B, 4B, B + M, M. |
| Optional Probe Detail | 3.5MHz Convex Probe | 2.0MHz, 2.5MHz, 3.5MHz, 4.0MHz, 5.0MHz
Depth range: 307mm Visual adjustable |
| 7.5MHz Linear probe | 5.5MHz, 6.5MHz, 7.0MHz, 7.5MHz, 9.0MHz
Depth range: 35-104mm |
| 6.5MHz Transvaginal probe | 5.0MHz, 5.5MHz, 6.5MHz, 7.5MHz, 8.5MHz
Depth range: 62-139mm |
| 5.0MHz Micro-Convex probe | 4.0MHz, 4.5MHz, 5.0MHz, 6.5MHz, 7.0MHz
Depth range: 62-139mm |
| 7.5MHz Rectal Probe | 5.5MHz, 6.5MHz, 7.0MHz, 7.5MHz, 9.0MHz |
| System Language | Chinese/ English/ Russian/ Spanish/ French/ Portuguese |
| Focus | 4 |
| Position Marker | ≥ 96 kinds |
| Image Mirroring | Up and down, left and right, black and white , in any mode can be changed and operated.
Images can be 0 °, 90 °, 180 °, 270 °, 360 ° rotation
|
| Character Display | Date, time, name, sex, age, doctor, hospital, comment (full screen character editing) (can be mixed with letters, numbers, punctuation, arrows) |
| Interface | RS-232, VGA, VIDEO, 2 USB ports, DICOM |
| Image post-processing function | DBF, DRF, DRA, THI, RDA, DFS, RDF |
| Display | 12.1 inch medical LED display |
| Battery | 10400mA built-in rechargeable lithium battery (4-8H) |
| Storage | Built in 8G memory card to save more than 4000 images, supporting U disk storage . |
| External Size(mm) | 330x 289x70 |
| N.W./G.W. (kg) | 4.7/9.5 |
| The 2D-dimensional imaging mode: |
| Gray scale | 256 level, 7 kinds, can be adjustable |
| Dynamic range | 0-135dB |
| Focus | 1-4 focus optional, adjustable focus position continuously |
| TGC | 8 segments |
| Tissue Harmonics | 0-1MHZ |
| Playback Frame | ≥ 512 frames, can be continuous to play or view by line. |
Frame correlation
| 4 kinds, adjustable |
| Line correlation | 6 kinds, adjustable |
| Gamma correction | 8 kinds,adjustable |
| Edge enhancement | 4 kinds, visual adjustable |
| Scanning range | 4 kinds, adjustable |
| Zoom function | Overall zoom |
| Image level adjustment | 0-1 |
| Black and white flip | 0-1 |
| Depth adjustment | 16 level |
| Gain | 0 ~ 100 adjustable |
| Scanning speed | 0-7 |
| M pseudo color | 0-7 |
| Blind Zone | ≤ 4 |
| Geometric Accuracy | Horizontal ≤ 5%, vertical ≤ 5% |
| Resolution | lateral ≤ 2mm, axial ≤ 1mm |
