In laboratories, multiple sample processing tasks are often required, our Multi-position hotplate magnetic stirrer is designed precisely for this purpose. It combines independent channel control, efficient constant-temperature heating, compact, space-saving form factor. It is the ideal choice whether for routine sample preparation, synthetic reactions, constant-temperature stirring or other laboratory operations.
Multi-Position Magnetic Stirrer Feature:
Ceramic-coated aluminum alloy work surface: acid and alkali resistant, corrosion resistant, provides uniform heat conduction, and is highly durable, reducing laboratory equipment maintenance costs.
Brushless motor+precise PID temperature control: stable operation, suitable for temperature-sensitive experiments, ensuring accurate and repeatable experimental data.
4/6-channel independent control: allows multiple experiments to be conducted in parallel, significantly increasing experimental throughput and improving overall laboratory efficiency.
Real-time monitoring of operating status: automatic overheating alarm and sensor malfunction detection to mitigate experimental risks and ensure operational safety.
Built-in short-circuit protection: immediate power cut-off in case of failure, comprehensively protecting the safety of operators and equipment, and complying with laboratory safety regulations.
Multi-Position Magnetic Stirrer Specification:
Model | HMS-P280S4 | HMS-P280S6 | MMS-S4 | MMS-S6 |
|---|
Number of Stirring Position | 4 | 6 | 4 | 6 |
Speed/Temp. Display | LCD |
Work Plate Dimension | Φ134 mm |
Max. Stirring Volume Per Position (H2O) | 3 L |
Max. Magnetic Bar (Length) | 40 mm |
Speed Range | 200–1500 rpm |
Speed Control Accuracy | ±20 rpm |
Work Plate Material | Aluminum with ceramic coating |
Motor Type | Brushless DC motor |
Heating Temperature Range | 25–280 ℃ | - | - |
Overheating Protection | 420 ℃ | - | - |
Resolution | 0.1 ℃ | - | - |
Accuracy | ±1 ℃(<100 ℃), ±1%(>100 ℃) | - | - |
External Temperature Sensor | PT1000 (Accuracy ±0.2℃, optional) | - | - |
Protection Class | IP21 |
Power Supply | 100–120 V, 60 Hz | 100–240 V, 50/60 Hz |
Motor Rating Output | 5W×4 | 5W×6 | 5W×4 | 5W×6 |
Heating Power | 600W×4 | 600W×6 | - | - |
Consumption | 605W×4 | 605W×6 | 5W×4 | 5W×6 |
External Size (W×D×H)(mm) | 701×265×127 | 564×523×127 | 701×265×127 | 564×523×127 |
Shipping Size (W×D×H)(mm) | 810×390×250 | 640×600×230 | 810×390×250 | 640×600×230 |
N.W./G.W. (kg) | 8.7/10.8 | 12.7/16.2 | 8.7/10.8 | 12.7/16.2 |
Permissible Ambient Temperature & Humidity | 5–40 ℃, 80% RH |
