HMS-PM features systematic optimizations in magnetic output, acceleration/deceleration control, heating mode selection, and safety protection. It helps you easily handle high-viscosity polymers, concentrated culture media, and long-duration synthesis processes.
Hotplate Magnetic Stirrer Feature:
High-energy rare-earth magnets significantly enhances magnetic coupling strength, ensuring stable stirring even in high-viscosity media and preventing stir bar skipping or stalling.
Powerful brushless DC motor provides ample torque reserve, easily handling diverse stirring requirements from low-viscosity buffer solutions to high-viscosity slurries.
Soft-start and progressive braking control algorithm ensures a smooth transition from high speed to stop, significantly reducing the risk of liquid spillage.
Three heating modes: rapid, standard, and stable, flexibly matching the heating needs of different experiments, balancing efficiency and accuracy.
Configurable with dual sensors (built-in+external PT1000), external temperature control accuracy ±0.2℃, with minimal fluctuation and high stability.
Residual heat warning: When the heating plate exceed 50°C, the display will automatically flash ‘HOT’ as a warning, remaining visible even once the power has been switched off.
Hotplate Magnetic Stirrer Specification:
Model | HMS-PM |
|---|
Speed/Temp. Display | LCD |
Work Plate Dimension (W×D) | Φ135 mm (5 inch) |
Max. Stirring Volume (H2O) | 20 L |
Max. Magnetic Bar (Length) | 80 mm |
Speed Range | 50–1500 rpm |
Timer | 1min to 99h59min |
Work Plate Material | Aluminum with ceramic coating |
Motor Type | Brushless DC motor |
Heating Temperature Range | RT.to 340 ℃ (1℃ step) |
Overheating Protection | 420 °C |
Temperature Control Accuracy | ±1℃(<100℃), ±1%(>100℃) |
Temperature Display Accuracy | ±0.1 °C |
External Temperature Sensor | PT1000 (Accuracy ±0.2℃, optional) |
Protection Class | IP21 |
Residual Heat Warning | 50°C |
Interface | RS232 |
Power Supply | 100–120/200–240 V, 50/60 Hz |
Motor Output Power | 10 W |
Heating Output Power | 600 W |
Consumption | 720 W |
External Size (W×D×H)) | 160×280×100 mm |
Shipping Size (W×D×H) | 490×350×260 mm |
N.W./G.W. | 2.8/4.9 kg |
Permissible Ambient Temperature & Humidity | 5–40 ℃, 80% RH |
