Plate: 96-well and 384-well plates Wavelength Selection: Filters (330-900 nm) Incubation Temperature: RT+4℃ to 55℃ Data Export: USB Sizes (W×D×H) : 290×400×220 mm
The ELMR-384 is a reliable and flexible microplate reader which can measure the absorbance. Its wavelength range is 330 nm to 900 nm with an accuracy of 0-6 Abs.
The ELMR-384 is a reliable and flexible microplate reader which can measures the absorbance. It provides reliable and qualified results by the high quality photometer through the built-in powerful software. By the big 10’ colorful touch screen, the user enjoys the intuitive operation on the system. And the visual user friendly interface with the logical workflow ensures the excellent usability, making it ideal for various fields in the research laboratories, such as Immunoassays (ELISA), protein assays (BCA, Lowry, Bradford). endotoxins, cytotoxicity and proliferation assays, enzyme assays, growth curves.
Elisa Microplate Reader Feature:
1. Wide wavelength range of 330nm to 900nm with an accuracy of 0-6 Abs absorption range. Scientific design of optical system to ensure the accurate measuring results. The optimum design and the verification of the optical path and circuit, meet the wide detection range from 330-900 mm wavelength.The detection results of each band are accurate and stable, applicable to a variety of rigorous applications.
2. Easy but powerful software with its logical workflow for universal usability. The stable and reliable performance comes from the built-in self-diagnostic program of the machine. In the start-up stage, the built-in self-diagnostic program detects the position of the microplate, and the stability of optical components.
The powerful internal software’s functions include:
(1) Main: protocol, plate format, measurement, shaking, incubation;
(3) Results: raw data, calculated results, Standardized Curve, quality control, results in list format;
(4) Settings: system,filters, Temperature, Other.
3. Two modes of operation: touch screen and PC. 10-inch high-definition color touch screen displays more inspection data. Its large icons is easy for touch operation and minimize misoperation, making it simple and intuitive. Standard PC operating software for convenient operation. It supports wired/wireless connection to computer.
4. Fast reading of both 96 well and 384 well microplates.
5. Shaking and incubation from RT+4'C to 55℃ for temperature critical assays.
6. 8 filters wheel with four preset filters.
7. High sensitive detector.
8. USB port for easy data transfer, connecting to printer.
Elisa Microplate Reader Specification:
Model
ELMR-384
Plate
96-well and 384-well plates
Light Source
Quartz-halogen lamp
Detector Type
Photo detector
Wavelength Selection
Filters (330-900 nm)
Filters Wheel
8 filters wheel; Filters installed: 405nm, 450nm, 492nm and 630nm. Additional filters can be ordered separately
(0-3Abs ± 2% in rapid measure mode, 0-4 Abs ± 2% in common measure mode)
Readout Range
0-6 Abs
Absorbance Resolution
Abs 0.001
Accuracy
± 1% (0-3 Abs) @ 405 nm; ± 2% (3-4 Abs) @ 405 nm
Precision
CV ≤ 0 .2% (0-3 Abs); CV ≤1% (3–4 Abs) @ 405 nm
Shaking
Linear shaking with three modes: slow, medium, fast
Measurement Speed
8 seconds, 96-well plate, fast mode; 12 seconds, 96-well plate, normal mode; 16 seconds, 384-well plate, fast mode; 24 seconds, 384-well plate, normal mode
Incubation Temperature
RT+4℃ to 55℃ (configured for standard)
Display
10-inch HD color touch screen
Data Export
USB
Printer
USB/WiFi
PC Software
Configured for standard
Power Supply
AC100-240V 50-60Hz
Size (W×D×H)
290×400×220 mm
Application:
The ELMR-384 is a reliable and flexible microplate reader which can measures the absorbance. It provides reliable and qualified results by the high quality photometer through the built-in powerful software. By the big 10’ colorful touch screen, the user enjoys the intuitive operation on the system. And the visual user friendly interface with the logical workflow ensures the excellent usability, making it ideal for various fields in the research laboratories, such as Immunoassays (ELISA), protein assays (BCA, Lowry, Bradford). endotoxins, cytotoxicity and proliferation assays, enzyme assays, growth curves.
Elisa Microplate Reader Feature:
1. Wide wavelength range of 330nm to 900nm with an accuracy of 0-6 Abs absorption range. Scientific design of optical system to ensure the accurate measuring results. The optimum design and the verification of the optical path and circuit, meet the wide detection range from 330-900 mm wavelength.The detection results of each band are accurate and stable, applicable to a variety of rigorous applications.
2. Easy but powerful software with its logical workflow for universal usability. The stable and reliable performance comes from the built-in self-diagnostic program of the machine. In the start-up stage, the built-in self-diagnostic program detects the position of the microplate, and the stability of optical components.
The powerful internal software’s functions include:
(1) Main: protocol, plate format, measurement, shaking, incubation;
(3) Results: raw data, calculated results, Standardized Curve, quality control, results in list format;
(4) Settings: system,filters, Temperature, Other.
3. Two modes of operation: touch screen and PC. 10-inch high-definition color touch screen displays more inspection data. Its large icons is easy for touch operation and minimize misoperation, making it simple and intuitive. Standard PC operating software for convenient operation. It supports wired/wireless connection to computer.
4. Fast reading of both 96 well and 384 well microplates.
5. Shaking and incubation from RT+4'C to 55℃ for temperature critical assays.
6. 8 filters wheel with four preset filters.
7. High sensitive detector.
8. USB port for easy data transfer, connecting to printer.
Elisa Microplate Reader Specification:
Model
ELMR-384
Plate
96-well and 384-well plates
Light Source
Quartz-halogen lamp
Detector Type
Photo detector
Wavelength Selection
Filters (330-900 nm)
Filters Wheel
8 filters wheel; Filters installed: 405nm, 450nm, 492nm and 630nm. Additional filters can be ordered separately
