Bandwidth : 2.0 nm Focal Length : 160 mm Grating : 1200 lines/mm Wavelength Range : 325-1100 nm It provides long-lasting, reliable performance for various applications in scientific, pharmaceutical, and environmental analysis.
The visible spectrophotometer features a 7-inch multi-colour touchscreen with patented interface technology for clear and intuitive control and data visualisation. With a built-in thermal printer (SP-V2S model), it can generate instant hard copy reports for straightforward documentation. Ideal for educational, industrial and environmental applications, this cost-effective instrument delivers robust performance, simplified operation and dependable results.
Visible Spectrophotometer Feature:
1. 1.7-inch multi color touch-screen and patented technology to achieve simple and effective human-computer interaction with a clear display of test data.
2. A built- in thermal printer to achieve printout of test results so as to facilitate the formation and rention of data reports (SP-V2S model only).
3. A USB communication port and UVWIN8 professional data processing software (optional) to achieve data processing and mapping functions and storage of massive amounts of data files, and to facilitate the secondary development by customers.
4. Automatic wavelength setting, fast and accurate.
5. Functions such as wavelength scanning (SP-V2S model only), kinetic time scanning, automatic wavelength, linear regression, direct read-out of concentration, peak detection, regular printing etc.
6. Advanced power shut-down protection measures to memorize detected data, regression equation and instrument correction parameters to achieve fast initialization.
7. Tungsten lamp with lifetime protection.
Visible Spectrophotometer Specification:
Model
SP-V2
SP-V2S
Optical System
Single Beam
Display
7-inch multi color touch-screen
Wavelength Setting
Automatic
Bandwidth
2 nm
Wavelength Range
325–1100 nm
Absorbance Range
-0.301 to 4.000 A, 0.0–200.0% T, 0.000-9999 C
Scanning Speed
/
Fast-Medium-Slow
Wavelength Accuracy
±1 nm
Wavelength Repeatability
0.5 nm
Stray Light
≤0.1% T (at 360 nm NaNo2)
Photometric Accuracy
±0.5% T;
±0.004 Abs (0-0.5 A); ±0.008 Abs (0.5-1 A);
Photometric Repeatability
≤0.2% T;
±0.002 Abs (0-0.5 A); ±0.004 Abs (0.5-1 A);
Noise
100%T noise≤0.2%T; 0%T noise≤0.1%T;
Stability
≤±0.002 A(335-1090nm)
Interface
USB
Software
UVWin8 (standard)
Sample Rack
Standard 10 mm 4-position
Power Supply
AC 220±22 V, 50±1 Hz
Consumption
100 W
External Size (W×D×H)
480×370×240 mm
Shipping Size (W×D×H)
650×525×400 mm
N.W./G.W. (kg)
11.8/16.3
12/16.5
What are the unique advantages of Osram Tungsten Lamp?
A: Lifespan is extended by 2 to 3 times. Osram utilizes its leading "Halogen Cycle" technology to enable its products to have an effective lifespan of up to 3000-4000 hours. Osram Tungsten Lamp offer uniform beam, high signal-to-noise ratio, and consistently stable data.
Why do Osram Tungsten Lamp Spectrophotometer win over customers in tenders?
In international laboratory tenders, the source of core optical components is typically examined. Specifying "Light Source: Original OSRAM (Germany)" on the Compliance Table will earn a very high compliance score on the technical bid.
As a professional lab and medical equipment manufacturer, Scitek Global is certified by ISO 9001, ISO 13485, ISO 45001 and ISO 14001. Almost all our products are certified by ETL, CE and FDA .
Scitek Global looks forward to establishing cooperation with more distributors all over the world, and working together to create greater customer value.
