Our thermostatic shaking water bath is a superior laboratory instrument that combines precise temperature control with oscillatory mixing. Whether you are performing cell culture, biochemistry or other experimental applications, our thermostatic shaking water bath will be an indispensable partner in your lab. Buy thermostatic shaking water bath and experience the convenience and efficiency that advanced technology can bring to your research work. Now, the affordable shaking water bath is for sale at a low price.
Model | SK-WB12 | SK-WB24 | SK-WB48 |
---|---|---|---|
Control Mode | P. I. D (Microcomputer scans the micro-processing chip) | ||
Display Mode | LCD (Large liquid crystal screen) | ||
Oscillation Mode | Repeated | ||
Drive Mode | Track drive by single shaft | ||
Ambient Temperature Requirement (℃) | 15-35 | ||
Curve Programing Settings | Programing settings of repetition, steps and eight-section curves | ||
Safety Functions | Audio and light alarm for temperatures above or below the upper or lower limit; Alarm for speeds above or below the upper or lower limit; Sensor fault identification, stand-alone over-temperature protector, Stand-alone leakage or over-current protection and refrigerator overload protection. | ||
Additional Functions | Speed storage, automatic stop, temperature and speed correction, monitoring timer, clock display, startup after power again, parameter memory, parameter encryption, one-touch factory reset | ||
Temperature Control Range (℃) | Room temperature -100 | ||
Accuracy of Temperature (℃) | ±0.1 (At constant temperature) | ||
Temperature Uniformity (℃) | ±0.2 | ||
Speed Range (r/min) | 20-200 | ||
Speed Accuracy (r/min) | ±1 | ||
Amplitude of Rocking Plate (mm) | 25 | ||
Timing Range (min) | 0-999.59 | ||
Size of Rocking Plate/ mm | 430×320 | 590×390 | 780×586 |
Number of Rocking Plates | 1 | ||
Max Capacity | 250ml×12 or 500ml×8 or 1000ml×6 | 250ml×24 or 500ml×15 or 1000ml×8 | 250ml×48 or 500ml×30 or 1000ml×20 |
Capacity (L) | 46 | 82 | 170 |
Power (W) | 2200 | 2200 | 4000 |
Power Supply | AC 200~240V 50∽60Hz | ||
Material of Chamber | 316 stainless steel (With strong acid and alkali resistance and better corrosion resistance) | ||
Material of Outer Box | High-quality nodular cast iron, channel steel, angle steel, medium plates and cold rolled steel sheets | ||
Chamber Size (mm) | 510×380×240 | 700×455×260 | 940×660×275 |
Sizes (W×D×H)(mm) | 760×420×370 | 945×495×408 | 1240×700×760 |
Shipping Size (W×D×H)(mm) | 910×650×550 | 1100×710×570 | 1370×850×1020 |
N.W./G.W. (kg) | 56/65 | 68/120 | 133/180 |
Utilizing advanced PID control mode, the microprocessor chip scanning achieves precise temperature control and ensures high accuracy (±0.1℃) within the RT range to 100℃.
Thermostatic shaking water bath adopts a large LCD screen display, which intuitively and clearly shows the working status and setting parameters, providing a user-friendly operation experience.
Repetitive oscillation mode ensures the samples are uniformly mixed under temperature control, suitable for various experimental needs.
Single-axis rail drive enables smooth oscillation, which improves stability and durability and reduces maintenance costs.
25mm oscillating plate amplitude can be adjusted according to the user's experimental requirements, providing greater flexibility and applicability.
