Model | ICB-150MI | ICB-250MI | ICB-350MI | ICB-450MI | |
---|---|---|---|---|---|
Capacity(L) | 150 | 250 | 350 | 450 | |
Circulation Mode | Forced convection | ||||
Size(WxDxH) | Internal (mm) | 505x380x800 | 550x450x1050 | 550x550x1150 | 700x550x1200 |
External (mm) | 635x575x1425 | 680x660x1710 | 685x780x1860 | 830x760x1860 | |
Temperature | Range (℃) | 0~60 | |||
Fluctuation (℃) | ±0.5 | ||||
Resolution (℃) | 0.1 | ||||
Uniformity (℃) | ±1 | ||||
Sensor | PT100 | ||||
Controller | PID | ||||
Display | High efinition LCD | ||||
Timer | 1~9999min | ||||
Material | Internal | Mirror sainless steel | |||
External | Cold rolled steel electrostatic spraying exterior | ||||
Shelves | 3 | 3 | 3 | 4 | |
Test Hole (Optional) | Φ25, 50, 80, 100mm | ||||
Refrigerant | R134a (CFC free) | ||||
Safety Device | Leakage protector, over temperaure visible & audible alarm | ||||
Electricity | Voltage/Frequency | AC 220/110V, 50/60Hz | |||
Consumption (W) | 690 | 730 | 780 | 1320 | |
N.W./G.W. (kg) | 100/120 | 120/150 | 140/160 | 158/200 | |
Shipping Size (WxDxH) (mm) | 760x710x1610 | 800x760x1930 | 810x900x2020 | 900x1150x2080 | |
Optional | Test hole, spare shelf, internal socket, digital independent temp. limiter, intelligent LCD procedure temperature controller (Optional USB, RS485/232 port, and built-in printer) |
Observation window for easy viewing of chamber contents.
Adjustable shelf with minimum spacing of 30mm.
Corrosion-resistant brushed stainless steel inner chamber.
Efficient internal circulation system with high-quality fan.Back suction and bottom vertical air supply for improved ventilation and temperature uniformity.
Laser hollowed-out shelf for enhanced ventilation and temperature uniformity.
Intelligent control with large-screen LCD display.User-friendly menu-type operation interface. Running functions include fixed value and timing modes.
Energy-saving features such as synthetic silicone sealing strip to prevent heat loss.
Automatic adjustment of control parameters for optimal heating and energy consumption.
High efficiency and energy-saving compressor for stable temperature control and low power consumption.
Standard UV lamp with sterilization function.
