Application:
It can be applied to the field of quality management, cost control, formula researching, chemistry researching
laboratory and so on. And it also can be used to measure solvent, adhesive, paint, pitch, resin, chemical oils,
edible oil, food additives, drink, dairy products, chemical solution, modern energy, oil fuel,
fine chemical engineering, chemical reagent, chemistry researching laboratories,etc.
Advantage:
1. LCD display,data can be read directly.
2. Short measuring time, about 5s.
3. High accuracy of measuring.
4. Density value can be showed by one procedure. and it can measure repeatedly continuously rapid.
5. Simple operation, it does not need tedious debugging and operation, not affected by external
factors and temperature compared with traditional wechsler balance method and pycnometer
method densimeter, also stable and durable.
6. Very easy to clean measuring cup, and not limited by measuring diameter.
7. Take samples conveniently. and 50CC would be okay.
8. Coordinate with the operation of thermostatic tank to measure the proportion with the required temperature.
9. It adopt dedicated wind and dust cover, which is convenient to combine and durable.
10. Volatile liquid, corrosivity liquid, vicious liquid, strong acid and strong lye liquid can be measured quickly.
11. With RS-232C interface(standard); Printer is optional.
Specification:
Model DME-120L DME-300L Capacity 120 g 300 g Density Resolution 0.0001 g/cm3 0.001 g/cm3 Density Range 0.0001—99.9999 g/cm3 0.001—99.999 g/cm3 Measuring Type a: mobility liquid, viscous liquid, volatile liquid, corrosivity liquid,
high temperature liquid, suspension liquid, emulsion and so on
b: alcohol, scaling powder, essence, blood, sodium chloride, glycerol, electrolyte, diesel, refrigerating, hydrofluoric acid, dichloromethane, vitriol and so on
Measuring Principle Archimedes principle displacement method Measuring Mode 1 group Measuring Time About 5 seconds Sample Temperature Range Room temperature to 100 ℃ Memory Mode Memory in shorter time by one procedure Result Display Density value Specific Gravity Measuring Frame Stainless steel specific gravity measuring frame Setting Function Temperature setting, solution density setting, measuring weights setting Calibration Auto correction with one button, auto detection. Measuring Testing Distilled testing Output Interface RS-232, output and print testing data conveniently Standard Accessories Measuring frame, standard liquid measuring assembly (2 pcs stainless steel
pothooks, 1 pc glass weight, 1 pc stainless steel weight,2 pcs beakers), tweezer,
thermometer,100g weight, wind and dust cover,measuring support, power transformer
Optional Accessories Printer (can connect computer), anti-corrosive liquid measuring assembly Power Supply 220/110 V, 50/60 Hz External Size (W×D×H) 195×230×185 mm Shipping Size (W×D×H) 440×180*×345 mm N.W./G.W. 1.5 /4.5 kg
