This series is specifically designed for samples that require long-term static storage, using circular buckets to store cells, tissues, or other biological samples. The product is durable, lightweight, and has many advantages such as a 5-year vacuum guarantee. Standard stainless steel bucket;
Laboratory Liquid Nitrogen Tank Feature:
The buckets are distinguished by different colors for easy and quick sample identification;
Durable aluminum structure and vacuum insulation design;
Small mouth design reduces liquid nitrogen consumption;
Standard safety lock buckle provides more security for samples;
Laboratory Liquid Nitrogen Tank Specifications:
| Model | LNC-015-30B | LNC-2-30B | LNC-2-35B | LNC-3-50B | LNC-6-50B |
|---|
| Capacity (L) | 1.5 | 2 | 2 | 3.15 | 6 |
| Number of handle buckets | 3 | 3 | 3 | 6 | 6 |
| Bucket diameter (mm) | 19 | 19 | 25 | 38 | 38 |
| Bucket height (mm) | 120 | 120 | 120 | 120 | 120 |
| Straw capacity 0.25ml | 195 | 195 | 345 | 1716 | 1716 |
| Straw capacity 0.5ml | 90 | 90 | 159 | 792 | 793 |
| Number of cryovials that each bucket can hold | 1 | 1 | 1 | 5 | 5 |
| Number of cryotubes (3 cryotubes/cryo-strip) | 9 | 9 | 9 | 90 | 90 |
| Number of cryotubes (6 cryotubes/cryo-strip) | —— | —— | —— | —— | —— |
| Static evaporation rate (L/day) | 0.071 | 0.071 | 0.11 | 0.12 | 0.115 |
| Static liquid nitrogen storage days | 21 | 28 | 18 | 26 | 52 |
| Caliber (mm) | 30 | 30 | 35 | 50 | 50 |
| Overall height (mm) | 398 | 410 | 420 | 441 | 488 |
| External diameter (mm) | 180 | 224 | 195 | 224 | 300 |
| Empty weight (kg) | 1.7 | 2.5 | 2.9 | 3.5 | 5.3 |
| Model | LNC-6-80B | LNC-10-50B | LNC-10-80B | LNC-13-50B | LNC-15-50B |
|---|
| Capacity (L) | 6 | 10 | 10 | 13 | 15 |
| Number of handle buckets | 6 | 6 | 6 | 6 | 6 |
| Bucket diameter (mm) | 63 | 38 | 63 | 38 | 38 |
| Bucket height (mm) | 120 | 120 | 120 | 120/276 | 120 |
| Straw capacity 0.25ml | 4986 | 1716 | 4986 | 1716/2580 | 1716 |
| Straw capacity 0.5ml | 2250 | 794 | 2250 | 794/1200 | 794 |
| Number of cryovials that each bucket can hold | 14 | 5 | 14 | 5 | 5 |
| Number of cryotubes (3 cryotubes/cryo-strip) | 252 | 90 | 252 | 90 | 90 |
| Number of cryotubes (6 cryotubes/cryo-strip) | —— | —— | —— | 180 | 180 |
| Static evaporation rate (L/day) | 0.225 | 0.116 | 0.21 | 0.12 | 0.11 |
| Static liquid nitrogen storage days | 27 | 86 | 48 | 109 | 136 |
| Caliber (mm) | 80 | 50 | 80 | 50 | 50 |
| Overall height (mm) | 492 | 566 | 557 | 630 | 618 |
| External diameter (mm) | 300 | 300 | 300 | 300 | 396 |
| Empty weight (kg) | 5.6 | 6 | 6.3 | 8.4 | 10 |
| Model | LNC-20-50B | LNC-20-80B | LNC-30-50B | LNC-30-80B | LNC-30-125B |
|---|
| Capacity (L) | 20 | 20 | 31.5 | 31.5 | 31.5 |
| Number of handle buckets | 6 | 6 | 6 | 6 | 6 |
| Bucket diameter (mm) | 38 | 63 | 38 | 63 | 97 |
| Bucket height (mm) | 120/276 | 120/276 | 120/276 | 120/276 | 120 |
| Straw capacity 0.25ml | 1716/2580 | 4986/8532 | 1716/2580 | 4986/8532 | 11220 |
| Straw capacity 0.5ml | 794/1200 | 2250/3984 | 794/1200 | 2250/3984 | 6300 |
| Number of cryovials that each bucket can hold | 5 | 14 | 5 | 14 | 37 |
| Number of cryotubes (3 cryotubes/cryo-strip) | 90 | 252 | 90 | 252 | 666 |
| Number of cryotubes (6 cryotubes/cryo-strip) | 180 | 504 | 180 | 504 | 1332 |
| Static evaporation rate (L/day) | 0.12 | 0.225 | 0.124 | 0.214 | 0.35 |
| Static liquid nitrogen storage days | 168 | 89 | 254 | 147 | 90 |
| Caliber (mm) | 50 | 80 | 50 | 80 | 125 |
| Overall height (mm) | 688 | 701 | 681 | 681 | 736 |
| External diameter (mm) | 396 | 396 | 451 | 451 | 451 |
| Empty weight (kg) | 12.2 | 12.7 | 15.3 | 15.8 | 16.4 |
| Model | LNC-35-50B | LNC-35-80B | LNC-35-125B | LNC-47-127/6B | LNC-47-127/10B |
|---|
| Capacity (L) | 35.5 | 35.5 | 35.5 | 47 | 47 |
| Number of handle buckets | 6 | 6 | 6 | 6 | 10 |
| Bucket diameter (mm) | 38 | 63 | 97 | 97 | 72 |
| Bucket height (mm) | 120/276 | 120/276 | 120/276 | 120/276 | 120/276 |
| Straw capacity 0.25ml | 1716/2580 | 4986/8532 | 11220/21000 | 11220/21000 | 10600/16840 |
| Straw capacity 0.5ml | 794/1200 | 2250/3984 | 6300/9360 | 6300/9360 | 5000/7800 |
| Number of cryovials that each bucket can hold | 5 | 14 | 37 | 37 | 20 |
| Number of cryotubes (3 cryotubes/cryo-strip) | 90 | 252 | 666 | 666 | 600 |
| Number of cryotubes (6 cryotubes/cryo-strip) | 180 | 504 | 1332 | 1332 | 1200 |
| Static evaporation rate (L/day) | 0.124 | 0.2 | 0.36 | 0.36 | 0.36 |
| Static liquid nitrogen storage days | 286 | 178 | 99 | 131 | 131 |
| Caliber (mm) | 50 | 80 | 125 | 127 | 127 |
| Overall height (mm) | 735 | 760 | 805 | 730 | 730 |
| External diameter (mm) | 451 | 451 | 451 | 508 | 508 |
| Empty weight (kg) | 16.3 | 17.2 | 18 | 19.2 | 19.2 |
| Model | LNC-50-50B | LNC-50-80B | LNC-50-125B |
|---|
| Capacity (L) | 50 | 50 | 50 |
| Number of handle buckets | 6 | 6 | 6 |
| Bucket diameter (mm) | 38 | 63 | 97 |
| Bucket height (mm) | 120/276 | 120/276 | 120/276 |
| Straw capacity 0.25ml | 1716/2580 | 4986/8532 | 11220/21000 |
| Straw capacity 0.5ml | 794/1200 | 2250/3984 | 6300/9360 |
| Number of cryovials that each bucket can hold | 5 | 14 | 37 |
| Number of cryotubes (3 cryotubes/cryo-strip) | 90 | 252 | 666 |
| Number of cryotubes (6 cryotubes/cryo-strip) | 180 | 504 | 1332 |
| Static evaporation rate (L/day) | 0.24 | 0.3 | 0.36 |
| Static liquid nitrogen storage days | 209 | 167 | 139 |
| Caliber (mm) | 50 | 80 | 125 |
| Overall height (mm) | 777 | 777 | 820 |
| External diameter (mm) | 508 | 508 | 508 |
| Empty weight (kg) | 21 | 21 | 23 |
