Disintegration Time Limit Tester, Stainless Steel Disintegration Basket

Model : DTLT-BI

Disintegration Basket Material : Stainless steel tube
Disintegration Basket Round-trip Frequency : 30 times/min
Disintegration Basket Moving Distance Up and Down : 10mm±1mm
Temperature Control Accuracy : ≤±0.3℃
With advanced automated control system and easy operation, this disintegration time limit tester is widely used in pharmaceutical industry and drug discovery.

Disintegration Time Limit Tester Specifications:

Disintegration Basket MaterialStainless steel tube
Tube Length

30mm, inner; diameter: 13mm;

Inner diameter of the sieve: 710µm

Disintegration Basket Round-trip Frequency30 times/min
Disintegration Basket Moving Distance Up and Down10mm±1mm
Water Bath Temperature Control RangeRT~ 45℃
Temperature Control Accuracy≤±0.3℃
Power SupplyAC220/110V; 50/60Hz
Shipping Size(W×D×H)(mm)430x380x550
N.W./G.W. (kg)10/17

Disintegration Time Limit Tester Features:

  1. Disintegration time limit tester is equipped with a disintegration basket of high-quality stainless steel tubing to ensure durability and accuracy during disintegration testing.

  2. The high round trip frequency better mimics the movement of the human digestive system, providing more accurate disintegration time limit test results.

  3. Fast sample disintegration speeds increase test productivity.

  4. Extremely high-temperature control accuracy ensures that testing conditions are closely regulated and meet the standards required for disintegration testing.
