The high-precision gold purity tester will not damage the sample, suitable for the jewelry shop, pawn broking, bank, precious-metals recovery, jewelry factory, precious metals researching laboratories.etc.
In accordance with Archimedes principle water buoyancy method, GB/T1423 of precious metals testing standard, and so on.
Application:
The high-precision gold purity tester will not damage the sample, can quickly, easily, and accurately distinguish and test the K value of gold, the PT value of platinum, the purity percentage of other precious metals, and their density. It is suitable for the jewelry shop,pawn broking, bank, precious-metals recovery, jewelry factory, Gemstone Testing Center, precious metals researching laboratories.etc. It can measure precious metals such as gold, karat gold, platinum, platinum, and silver.
Precious Metal Densimeter Feature:
1. Quickly test the purity of gold, platinum, and other precious metals, distinguish fakes.
2. Non-destructive testing, clean and environmentally friendly, with no damage to the original sample.
3. Fast and convenient testing, just need 10 seconds, stable and accurate.
4. Multi-mode: freely switch between gold, platinum, and other precious metal modes.
5. Multi-function: it can measure the purity of other precious metals, such as tin, copper, and silver, can also be used as a precision balance.
6. With upper and lower limit functions:it displays OK, HI, LO based on the status of qualified, exceed,less with an alarm.
7. Cannot measure hollow samples or samples inlaid with gemstones.
8. With fully automatic zero tracking, buzzer alarm, and overload alarm functions.
9. Uses water as the medium, other liquids are also acceptable. The actual water temperature can be set.
10. Compared to traditional drop-in-water methods, this unit utilizes a single-piece, large-capacity measuring instrument. The water tank is corrosion-resistant, drop-resistant, and break-resistant, and the hanging wire will not affect the measurement results.
11. Standard with RS-232 output port.
12. Printer is optional,can print the testing result directly.
13. Standard with dedicated windproof and dust-proof cover,easy assembly.
14. High-precision, suitable for small samples and demanding applications.
Precious Metal Densimeter Specification:
Model
DME-120PM
DME-200PM
DME-300PM
DME-600PM
DME-900PM
DME-1200PM
DME-2000PM
DME-3000PM
Capacity (g)
120
200
300
600
900
1200
2000
3000
Display
LCD display
Weight Resolution (g)
0.001
0.001
0.005
(0.01 g
optional)
0.005
0.01
0.01
0.01
0.01
Necessary Weight for Density (g)
2
2
4
4
5
5
5
5
Density Resolution
0.001 g/cm3
Measuring Time
10 S
Testing Board
Completed high-capacity plastic testing board
Measuring Type
Traditional gold and platinum jewelry, necklace, bracelet, ring, large bullion, craft, and gold, silver, copper, cadmium, nickel, tin. etc.
Gold Mode
Display
K Value
The K value of mixture of gold, silver, and copper
The K value of mixture of gold and copper
The K value of mixture of gold and silver
Display
Purity
Percent
The purity percentage of mixture of gold, silver and copper
The purity percentage of mixture of gold and copper
The purity percentage of mixture of gold and silver
K Value Range
10~24 K
Copper
and Silver Proportion Setting
Cycle seting (default 7:3)
Testing Error
Default as ±1K; also can be set up as 0.1 K, 0.01 K, need to confirm with factory firstly
Platinum
Display Value
PT percent, density value, volume
Mode
PT Value Range
Pt600 - Pt1000
Other Precious Metals
Function
Only for DME-120PM and DME-200PM: measure the purity percentage of main materials in two kinds of mixture
Display Value
Only for DME-120PM and DME-200PM: density value, volume, content percentage
setting
Only for DME-120PM and DME-200PM: density value of main materials and secondary materials setting
Measuring Container
Completed injection forming transparent professional measuring tank (size (L×W×H): 169×98×83 mm)
Parameter Setting
Water temperature setting, measuring medium density setting
Principle
Archimedes principle
Memory Method
Two procedures
Correction Method
Auto calibration with one key, auto detection.
Output Method
Output and print testing data conveniently with standard communication interface of RS-232C.
Standard Accessories
Host, tank, test board, tweezer, thermometer, weight, wind and dust cover, a set of measuring particle parts, a set of measuring floating body parts, power transformer
Wind and Dust Cover
Adopt the unicase dedicated wind and dust cover
Option Accessories
Printer
Power
Default as AC 100 V–240 V (Europe standard),based on destination country which standards be took.
Main Features
Simple operation, digital display, accurate measuring, stable, durable.
External Size (W×D×H)
195×230×197 mm
Shipping Size (W×D×H)
440×180×345 mm
N.W./G.W. (kg)
1.6 / 4.5
1.8 / 4.5
1.8 / 5
1.9 / 5.5
Standard:
In accordance with Archimedes principle water buoyancy method, GB/T1423 of precious metals testing standard, and so on.
Application:
The high-precision gold purity tester will not damage the sample, can quickly, easily, and accurately distinguish and test the K value of gold, the PT value of platinum, the purity percentage of other precious metals, and their density. It is suitable for the jewelry shop,pawn broking, bank, precious-metals recovery, jewelry factory, Gemstone Testing Center, precious metals researching laboratories.etc. It can measure precious metals such as gold, karat gold, platinum, platinum, and silver.
Precious Metal Densimeter Feature:
1. Quickly test the purity of gold, platinum, and other precious metals, distinguish fakes.
2. Non-destructive testing, clean and environmentally friendly, with no damage to the original sample.
3. Fast and convenient testing, just need 10 seconds, stable and accurate.
4. Multi-mode: freely switch between gold, platinum, and other precious metal modes.
5. Multi-function: it can measure the purity of other precious metals, such as tin, copper, and silver, can also be used as a precision balance.
6. With upper and lower limit functions:it displays OK, HI, LO based on the status of qualified, exceed,less with an alarm.
7. Cannot measure hollow samples or samples inlaid with gemstones.
8. With fully automatic zero tracking, buzzer alarm, and overload alarm functions.
9. Uses water as the medium, other liquids are also acceptable. The actual water temperature can be set.
10. Compared to traditional drop-in-water methods, this unit utilizes a single-piece, large-capacity measuring instrument. The water tank is corrosion-resistant, drop-resistant, and break-resistant, and the hanging wire will not affect the measurement results.
11. Standard with RS-232 output port.
12. Printer is optional,can print the testing result directly.
13. Standard with dedicated windproof and dust-proof cover,easy assembly.
14. High-precision, suitable for small samples and demanding applications.
Precious Metal Densimeter Specification:
Model
DME-120PM
DME-200PM
DME-300PM
DME-600PM
DME-900PM
DME-1200PM
DME-2000PM
DME-3000PM
Capacity (g)
120
200
300
600
900
1200
2000
3000
Display
LCD display
Weight Resolution (g)
0.001
0.001
0.005
(0.01 g
optional)
0.005
0.01
0.01
0.01
0.01
Necessary Weight for Density (g)
2
2
4
4
5
5
5
5
Density Resolution
0.001 g/cm3
Measuring Time
10 S
Testing Board
Completed high-capacity plastic testing board
Measuring Type
Traditional gold and platinum jewelry, necklace, bracelet, ring, large bullion, craft, and gold, silver, copper, cadmium, nickel, tin. etc.
Gold Mode
Display
K Value
The K value of mixture of gold, silver, and copper
The K value of mixture of gold and copper
The K value of mixture of gold and silver
Display
Purity
Percent
The purity percentage of mixture of gold, silver and copper
The purity percentage of mixture of gold and copper
The purity percentage of mixture of gold and silver
K Value Range
10~24 K
Copper
and Silver Proportion Setting
Cycle seting (default 7:3)
Testing Error
Default as ±1K; also can be set up as 0.1 K, 0.01 K, need to confirm with factory firstly
Platinum
Display Value
PT percent, density value, volume
Mode
PT Value Range
Pt600 - Pt1000
Other Precious Metals
Function
Only for DME-120PM and DME-200PM: measure the purity percentage of main materials in two kinds of mixture
Display Value
Only for DME-120PM and DME-200PM: density value, volume, content percentage
setting
Only for DME-120PM and DME-200PM: density value of main materials and secondary materials setting
Measuring Container
Completed injection forming transparent professional measuring tank (size (L×W×H): 169×98×83 mm)
Parameter Setting
Water temperature setting, measuring medium density setting
Principle
Archimedes principle
Memory Method
Two procedures
Correction Method
Auto calibration with one key, auto detection.
Output Method
Output and print testing data conveniently with standard communication interface of RS-232C.
Standard Accessories
Host, tank, test board, tweezer, thermometer, weight, wind and dust cover, a set of measuring particle parts, a set of measuring floating body parts, power transformer
Wind and Dust Cover
Adopt the unicase dedicated wind and dust cover
Option Accessories
Printer
Power
Default as AC 100 V–240 V (Europe standard),based on destination country which standards be took.
Main Features
Simple operation, digital display, accurate measuring, stable, durable.
