Application:
The Visible Spectrophotometer features a 7-inch multi-colour touchscreen with patented interface technology
for clear and intuitive control and data visualisation. With a built-in thermal printer (SP-V2S model),
it can generate instant hard copy reports for straightforward documentation. Ideal for educational,
industrial and environmental applications, this cost-effective instrument delivers robust performance,
simplified operation and dependable results.
Advantage:
1. 1.7-inch multi color touch-screen and patented technology to achieve simple and effective human-computer
interaction with a clear display of test data.
2. A built- in thermal printer to achieve printout of test results so as to facilitate the formation and
rention of data reports (SP-V2S model only).
3. A USB communication port and UVWIN8 professional data processing software (optional) to achieve
data processing and mapping functions and storage of massive amounts of data files, and to facilitate the
secondary development by customers.
4. Automatic wavelength setting, fast and accurate.
5. Functions such as wavelength scanning (SP-V2S model only), kinetic time scanning, automatic wavelength,
linear regression, direct read-out of concentration, peak detection, regular printing etc.
6. Advanced power shut-down protection measures to memorize detected data, regression equation and
instrument correction parameters to achieve fast initialization.
7. Tungsten lamp with lifetime protection.
Specification:
Model SP-V2S SP-V2 Photometry Single Beam Monochromator Type Czerny-Turner Focal Length 160 mm Grating 1200 lines/mm Detector Silicon Photocell Spectrum Bandwidth 2 nm Wavelength Setting 7-inch color touch-screen Wavelength Range 325-1100 nm Wavelength Accuracy ±1 nm Wavelength Repeatability ≤0.5 nm Scanning Speed Fast-Medium-Slow Stray Light ≤0.1% T (at 360 nm NaNo2 ) Photometric Range 0.0-200.0% T; Photometric Accuracy ±0.5% T; Photometric Repeatability ≤0.2% T; Noise 100%(T) noise≤0.2%(T); Power AC 220±22 V, 50±1 Hz, 100 W Standard Accessories Operation manual 1pc; Optional Accessories UV WIN8 station pro software; External Size (W×D×H) 480×370×240 mm Shipping Size (W×D×H) 650×525×400 mm N.W/G.W. (kg) 11.8 / 16.3 12/16.5
