Rotary Evaporator, RE-50 Series

Model : RE-50A; RE-50C; RE-5300

Rotary Bottle : 1 L 24# (standard size)
Collecting Bottle : 0.5 L 24# (standard size)
Condenser : Vertical φ85×450mm, 29# (standard size)
Rotating Speed : 0~120 rpm
Vacuum : -0.098  Mpa
Temp. Range : RT~99 ℃
This rotary evaporator meets the highest expectations for convenience and versatility and is the first choice for small to medium sized laboratories.
Availability:
Quantity:

Meets the highest expectations in terms of convenience and versatility. All your basic needs in terms of vaporization can be met. The vaporizer allows precise setting of the rotation speed and heating bath temperature on the digital touchscreen display, which is quickly accessed directly through the knobs on the operating panel.

Rotary Evaporator Specifications:

Model RE-50A RE-50C RE-5300
Rotary Bottle 1 L 24# (standard size)
Collecting Bottle 0.5 L 24# (standard size)
Condenser Vertical φ85×450mm, 29# (standard size)
Charging Valve 19# (standard size)
Rotating Speed 0~120 rpm
Vacuum -0.098 Mpa
Temp. Range RT~99 ℃
Temp. Accuracy ±1℃
Stroke Height 150 mm
Rotating Power 30W
Heating Power 1KW
Chamber Material SS φ220×120mm SS φ245×140mm
Shelf Material Powder coating anticorrosive
Power Supply AC220V±10%, 50/60Hz; 110V, 60Hz
Standard Accessory 1000ml rotary bottle×1, 500ml recycling bottle×1
Optional Accessory RT~400℃ Oil bath, Transparent bath cover, Vacuum pump, Recirculating chiller
Sizes(W×D×H)(mm) 650×440×1000mm 650×440×1010mm
Shipping Size (W×D×H)(mm) 610×470×480mm
N.W./G.W. (kg) 15/20 16/21 16/21
Supporting Products RE-50A/50C/5300+Water Circulating Vacuum Pump (VP-DIII) + Low temperature cooling liquid circulator (LTC-20I)

Rotary Evaporator Features:

  1. Electronic stepless speed controll

  2. Explosion-proof function is optional

Details of Rotary Evaporator(RE-50C):

Rotary Evaporator

Rotary Evaporator

Precise operation control for repeatability and safety

RE-50C (4)
