It adopts special heating furnace to ensure the safety of test.
The heating power is continuously adjustable. It can meet requirements of test.
The open cup flash point tester is fully self-contained complete. The operator can do determination as long as connecting with coal gas or other civil gas.
With fast cooling function, it can improve test efficiency.
Open Cup Flash Point Tester Specifications:
Model
FPT-3536
Heating Device
Furnace heating, no naked fire, explosion prevented. The power is adjustable from 0W to 600W
Test Flame Applicator
It applies the test flame automatically
Thermometer
-6~400℃
Thermometer Scale
2℃
Igniting Device
Ignition source: coal gas (or civil gas)
Nozzle aperture: about 0.8mm
Ambient Temperature
15~35℃
Relative Humidity
≤85%
Power Supply
AC(220±10%)V, 50Hz
Power Consumption
≤650W
Size(W×D×H)(mm)
350×290×350 (thermometer is not included)
Net Weight
5.5kg
Package Size (W×D×H)(mm)
650x450x420
Gross Weight
19.6kg
What is an open cup flash point tester? What is it used to measure?
An open cup flash point tester is a laboratory instrument used to determine the flash point and fire point of petroleum products, lubricants, chemicals, and other flammable liquids. The flash point is the lowest temperature at which the vapor of a sample will ignite instantly upon contact with an open flame under specified test conditions. The fire point is the temperature at which the sample can sustain combustion for at least 5 seconds. This test is critical for safety classification, quality control, and regulatory compliance in industries such as petrochemicals, aviation, maritime transport, and power generation.
