Non-Touched fully automatic ultrasonic disruptor (cup-type ultrasonic cell crusher) is commonly used for cell crushing, lysis, and release of cell particles. Especially for the release of adenovirus particles, it is not only suitable for preparing high-titer recombinant adenovirus, but also can prepare viral DNA and DNA terminal protein compounds. It is also an ideal instrument for soil sample preparation. It has become an indispensable standardized tool for CHIP (chromatin immunoprecipitation) research platform.
The non-touched fully automatic ultrasonic crusher can detect 4-16 samples at a time, with high experimental efficiency; there is no need to frequently operate the probe, and each sample is in a separate fully enclosed test tube to avoid cross-contamination; the ultrasonic energy is evenly distributed and the ultrasonic effect Complete; flexible ultrasonic parameter settings, standardized experimental procedures, good experimental repeatability, and high reliability of results.
Large screen LCD display.
It can simultaneously detect 4-16 samples at once, with high experimental efficiency.
No need to frequently operate the probe, all products are in separate fully enclosed test tubes to avoid cross contamination.
The sound-absorbing device is equipped with a handle door on the side for easy internal operation.
It can effectively prevent the production of sample foam.
Equipped with a cooling water circulation device interface.
Optional cooling water circulation device can be equipped to achieve constant temperature inside the system, effectively avoiding excessive sample temperature.
Model | UCD-NT1200 | UCD-NT2200 |
---|---|---|
Consumption | 12~1200W Manual Adjustable | 2200W Automatic Adjustable |
Single Sample Processing Capacity | 1.5/2mlx4 holes | 1.5/2mlx16 holes |
Display | Color 4.3-inch Capacitive Touch Screen | |
Single Ultrasound Time | 0.1~99.9s | |
Single Interval Time | 0.1~99.9s | |
Total Working Time | 1~99h59m59s | |
Frequency Range | 19.5~20.5KHz | |
Temp. Control Range | 0~100℃(Optional low-temperature constant temperature bath) | |
Alarm Function | Temperature, time, overload, no-load, over temperature | |
Ultrasonic Horn | Φ20mm*1 | Φ60mm |
Processing Room Cold Bath Function | NO | YES |
Date Storage | 20 set | |
Power Supply | AC110/220V 50/60Hz | |
Optional | PC communication, Printer | PC communication, Printer, Soundproof box lighting or sterilization |
Control Method | Single-Chip Microcomputer + TFT Touch Control | |
Voice Alarm & Prompt Function | Yes | |
Continuous Ultrasound | NO | YES |
Optional Adapter | 0.2mlx8 or 0.5mlx6ml or 5mlx3 | 0.5mlx18, 5mlx18, 15mlx15 |
Optional Touched Type Transducer | 3~1000ml | 3~1000ml or 50mlx5 |
Optional Ultrasonic Horn Matched with Touched Transducer | Φ3 or Φ6 or Φ10 or Φ15 or Φ20 | / |
Machine External Size(WxDxH)(mm) | 225x410x290 | |
Ultrasonic Host Net Weight(kg) | 10 | 7 |
Ultrasonic Host Gross Weight(kg) | 12 | 10 |
Ultrasonic Host Packaging Size(LxWxH)(mm) | 470x305x430 | |
Processing Room Gross Weight(kg) | 12 | 19 |
Processing Room Packaging Size (LxWxH)(mm) | 320x320x700 | 510x420x470 |
