Embedded light sources on two side walls, delivering uniform horizontal light radiation and effectively eliminating "dead zones" caused by shelf obstruction. This significantly enhances space utilization and the accuracy of multi-layer parallel experiments. Widely used for tall crops, multi-layer high-density plant tissue culture, tobacco tolerance studies, the rearing of phototactic insects, and algae cultivation.
Lighting Incubator Feature:
Cold-rolled steel exterior with electrostatic spray, 304 stainless steel interior, polyurethane foam insulation,adjustable stainless steel shelves.
7-inch color touch screen. supports multi-touch, password lock, and 3-level authority management.
Auto-generated historical curves/data on screen, USB port for data export.
Controller alerts for faults with specific error details, system records operation logs for data traceability.
400-780nm full-spectrum cold light source, scientific spectral ratio for plant growth.
Aluminum alloy heat dissipation bracket for light sources, low heat generation extends lifespan.Fully transparent protective shield for each lamp bead.
Snap-in side-mounted light modules for horizontal irradiation, quick-plug connectors allow tool-free replacement.
Direct input of required intensity or percentage adjustment.
Imported compressor units and eco-friendly refrigerants, full steel heat exchangers.
High-temperature PID heating technology with sheet-type stainless steel heaters.
Low-noise axial fans with specially designed air ducts, gentle wind for uniform environment.
Mechanical door lock for sample safety, natural ventilation function ensures fresh air inside.
Lighting Incubator Specification:
Model | ICB-160LS | ICB-300LS | ICB-500LS | ICB-700LS | ICB-1000LS | ICB-1500LS |
Capacity (L) | 160 | 300 | 500 | 700 | 1000 | 1500 |
Circulation Mode | Forced Air Circulation |
Internal Size (W×D×H)(mm) | 500×450×750 | 550×520×1050 | 660×660×1150 | 930×660×1150 | 1320×660×1150 | 1980×660×1150 |
Shelves (pcs) | 2 | 3 | 4 | 4 | 4 | 4 |
Display | 7-inch LCD touch screen |
Temperature Range | With Light: 5–50 °C, without Light: 0–50 °C |
Temperature Resolution | 0.1 °C |
Temperature Fluctuation | ±1 ℃ (Tested at no load, ambient temperature 20°C, 50% RH humidity) |
Temperature Uniformity | ±1 ℃ (Tested at no load, ambient temperature 20°C, 50% RH humidity) |
Illuminance | 25000 Lux (Side light) |
Illumination Control | Stepless dimming |
Timer | 5 programs × 100 segments, 0-9999 min per segment |
Refrigerant | R134a | R404a | R22 | R404a |
Power Supply | AC 220/110V, 50/60Hz |
Consumption (W) | 1050 | 1150 | 1650 | 1650 | 2450 | 3650 |
External Size (W×D×H)(mm) | 600×590×1480 | 650×660×1780 | 760×800×1880 | 1030×800×1880 | 1420×800×1880 | 2080×800×1880 |
Shipping Size (W×D×H)(mm) | 660×690×1540 | 760×790×1830 | 880×910×1930 | 1140×880×1930 | 1500×860×1930 | 2160×910×1930 |
G.W (kg) | 120 | 145 | 195 | 235 | 280 | 462 |
Optional Accessory | Internal power socket, UV lamp, built-in micro printer, 50 mm test hole |
Ambient Temperature | 5–35 ℃ |
