The product shell is made of high-quality cold plate, and the surface is treated by spraying process.
The inner chamber is 304 stainless steel.
Extra-large double-layer tempered glass observation window, convenient for observing the changes of items in the box.
Adopt new synthetic silicone sealing strips, beautiful appearance, long-term high-temperature operation, longer service life.
The hot air circulation system adopts low-noise self-heating fan to ensure longer service life of the fan and more uniform temperature in the box. The equipment is equipped with a fan speed switch, and the user can adjust the wind speed according to needs.
Program control instrument, printer, 485 interface, USB disk storage, SMS alarm and other functions can be installed.
Model | HDO-45BE | HDO-70BE | HDO-140BE | HDO-210BE | HDO-240BE |
---|---|---|---|---|---|
Capacity | 42L | 70L | 136L | 210L | 245L |
Voltage/Frequency | 220V 50Hz; 110V 60Hz | ||||
Temperature Range | RT+10~300℃ | ||||
Temperature Resolution | 0.1℃ | ||||
Temperature Fluctuation | ±1℃ | ||||
Temperature Uniformity | ±1℃ | ||||
Consumption (W) | 1000W | 1500W | 2000W | 3000W | 3000W |
Internal Size(WxDxH)(mm) | 340x345x345 | 340x450x450 | 440x545x545 | 500x600x700 | 490x695x695 |
External Size(WxDxH)(mm) | 465x650x525 | 510x750x620 | 570x850x725 | 660x900x870 | 615x1000x880 |
Package Size(WxDxH)(mm) | 580x720x600 | 565x805x705 | 675x900x800 | 720x970x950 | 720x1050x950 |
Shelves(Standard / Max) | 2/4 | 2/6 | 2/8 | 2/10 | 2/10 |
Gross Weight | 41kg | 47kg | 64kg | 80kg | 87kg |
Internal Material | 304 Stainless steel |
The product shell is made of high-quality cold plate, and the surface is treated by spraying process.
The inner chamber is 304 stainless steel.
Extra-large double-layer tempered glass observation window, convenient for observing the changes of items in the box.
Adopt new synthetic silicone sealing strips, beautiful appearance, long-term high-temperature operation, longer service life.
The hot air circulation system adopts low-noise self-heating fan to ensure longer service life of the fan and more uniform temperature in the box. The equipment is equipped with a fan speed switch, and the user can adjust the wind speed according to needs.
Program control instrument, printer, 485 interface, USB disk storage, SMS alarm and other functions can be installed.
Model | HDO-45BE | HDO-70BE | HDO-140BE | HDO-210BE | HDO-240BE |
---|---|---|---|---|---|
Capacity | 42L | 70L | 136L | 210L | 245L |
Voltage/Frequency | 220V 50Hz; 110V 60Hz | ||||
Temperature Range | RT+10~300℃ | ||||
Temperature Resolution | 0.1℃ | ||||
Temperature Fluctuation | ±1℃ | ||||
Temperature Uniformity | ±1℃ | ||||
Consumption (W) | 1000W | 1500W | 2000W | 3000W | 3000W |
Internal Size(WxDxH)(mm) | 340x345x345 | 340x450x450 | 440x545x545 | 500x600x700 | 490x695x695 |
External Size(WxDxH)(mm) | 465x650x525 | 510x750x620 | 570x850x725 | 660x900x870 | 615x1000x880 |
Package Size(WxDxH)(mm) | 580x720x600 | 565x805x705 | 675x900x800 | 720x970x950 | 720x1050x950 |
Shelves(Standard / Max) | 2/4 | 2/6 | 2/8 | 2/10 | 2/10 |
Gross Weight | 41kg | 47kg | 64kg | 80kg | 87kg |
Internal Material | 304 Stainless steel |
