Glass Ceramic Hotplate

Model : HC-G550

Work Plate Size (WxD) : 184x184mm (7 inch)
Work Plate Material : Glass ceramic
Heating Position : 1
Heating Temperature Range : Room temp.-550°C, increment 5°C
Heating Power : 1010W

The best glass ceramic hotplate is designed to be rugged and reliable for heating in the lab or institute. It provide excellent safety and temperature performance for heating.

Availability:

Quantity:



Inquiry Add to Inquiry List

Product Description

This glass hotplate will meet the needs of any lab. The ceramic surface ensures more even heating. This glass ceramic hotplate can be used to heat glass beakers, conical flasks and other scientific glassware. The heating temperature is stable and durable with good safety and convenience.

Top Glass Ceramic Hotplate Specifications:

Model	HC-G550
Work Plate Size (WxD)	184x184mm (7 inch)
Work Plate Material	Glass ceramic
Heating Position	1
Heating Temperature Range	Room temp. -550°C, increment 5°C
Control Accuracy of Work Plate	±10°C
Safety Temperature	580°C
Temperature Display	LED
Temperature Display Accuracy	±1°C
External Temperature Sensor	PT1000(±0.5°C)
Heating Warning	50°C
Protection Class	IP21
Power	1010W
Permissible Ambient Temperature and Humidity	5-40°C, 80%RH
Voltage Frequency	100-120/200-240V, 50/60Hz
Heating Power	1000W
Sizes(W×D×H)(mm)	360x215x112
Shipping Size(W×D×H)(mm)	490x350x260
N.W./G.W. (kg)	4.5/6
