Climate Chamber Specifications:
| Model | ICB-250C | ICB-350C |
|---|
| Capacity(L) | 250 | 350 |
| Circulation Mode | Forced convection |
| Size(WxDxH) | Internal (mm) | 555x450x1100 | 550x550x1200 |
| External (mm) | 680x680x1760 | 780x780x1900 |
| Temperature | Range (℃) | With lighting: 10~60; Without lighting: 4~60 |
| Fluctuation (℃) | ±1 |
| Resolution (℃) | 0.1 |
| Uniformity (℃) | ±1 | ±2 |
| Sensor | PT100 |
| Humidity | Range | 50~90%RH |
| Stability | ±5 ~ ±7 % |
| Method | Internal |
| Sensor | High precision anti-condensation |
| Illumination(Lx) | 0~12000 | 0~15000 |
| Illumination Control | 6-level relative illuminance control |
| Controller | PID |
| Display | Large high efinition LCD |
| Timer | 1~9999min (Optional 30xsegmentsx100cycles) |
| Material | Internal | Stainless steel |
| External | Cold rolled steel electrostatic spraying exterior |
| Shelves | 3 |
| Test Hole (Optional) | Φ 25,50,80,100mm |
| Internal Socket | Optional |
| Refrigerant | R134a (CFC free) |
| Defrosting Mode | Automatic |
| Safety Device | Visible & Audible over temperaure, over humidity, water shortage alarm; leakage protector |
| Electricity | Voltage/Frequency | AC 220/110V, 50/60Hz |
| Consumption (W) | 880 | 1640 |
| N.W./G.W. (kg) | 120/150 | 140/285 |
| Shipping Size (WxDxH) (mm) | 820x800x1920 | 1020x920x2090 |
| Optional | Test hole, spare shelf, internal socket, digital independent temp. Limiter, intelligent, LCD procedure temperature controller (Optional USB, RS485/232 port and built-in printer) |
Climate Chamber Features:
Large-screen LCD display for easy monitoring.
Three-stage electric heating defrosting program control for efficient defrosting.
Back suction and bottom vertical air supply circulation system for optimal airflow.
Laser hollowed-out shelves with round holes for improved ventilation and temperature uniformity.
Adjustable shelves with minimum spacing of 30mm for flexible storage.
Reality:
Equipped with leakage protection device for operator and equipment safety.
Temperature control sound and light alarm system for precise monitoring.
Self-diagnosis function to display fault information for easy troubleshooting.
Waterproof stainless steel heating tube for corrosion resistance and long service life.
