Cabinet-type Pulse Vacuum Sterilizer

Model : ST-H60PVI; ST-H80PVI; ST-H100PVI; ST-H135PVI; ST-H150PVI; ST-H185PVI; ST-H200PVI; ST-H300PVI; ST-H450PVI; ST-H500PVI

Capacity : 100L/130L/150L
Chamber Size(WxDxH) : 700x430x360mm; 750x450x400mm; 820x645x400mm
Sterilizer Solution : 2% formaldehyde, 3% alcohol, and 95% distilled water solution
Sterilizer Solution Packaging Specification : 2L
External Size(WxDxH) : 1070x790x1770mm
High-performance, fully automated start-to-finish sterilisation through autoclaving and drying steps.
Availability:
Quantity:

The ST-H series cabinet-type pulsating vacuum sterilizer utilizes saturated steam as the sterilization medium. Through pulsating vacuum, the saturated steam completely penetrates the surface of the items, using high temperature and pressure to kill all microorganisms and their spores. The sterilization effect is reliable, making it the most effective method in physical sterilization. It is widely used in pharmaceuticals, biotechnology, laboratories, and other fields to sterilize items such as fabrics, sterile clothing, instruments, tools, luminal instruments, rubber, liquids, and culture media.

Pulse Vacuum Sterilizer Features:

  1. Using microcomputer control technology and touch screen operation, the entire process (pulse vacuum, heating, sterilization, exhaust, vacuum drying) runs automatically.

  2. The touch screen automatically displays the running process status, temperature, pressure, time, and other parameters, as well as fault alarm information.

  3. There are four sterilization programs available for instruments, dressings, luminal instruments, rubber, liquids, and custom options, as well as BD testing and vacuum testing programs for users to choose from.

  4. The built-in vacuum pump allows for three pulsating vacuums (adjustable), with a vacuum degree of up to -0.090 MPa, which can completely remove air from dressings and Class A luminal instruments.

  5. The built-in efficient steam generator can quickly generate constant-pressure steam without contaminating sterilized items.

  6. The vacuum drying system ensures fabric drying below 1% and instrument drying below 0.1%.

  7. A 0.22μm bacterial air filter is included to ensure that the air introduced after breaking the vacuum is sterile, avoiding recontamination.

  8. An optional mini printer can be selected to record real-time sterilization processes and fault alarm information.

  9. Automatic calibration of atmospheric pressure is available to avoid high-altitude reactions.


Safety Function

  1. Over-temperature protection device: When the temperature of the pot exceeds the set temperature, the system automatically cuts off the heating power and displays an alarm.

  2. Door safety interlock device: The program can only start when the door is closed properly; the door cannot be opened when there is dangerous pressure in the inner chamber.

  3. Dual overpressure protection: Automatic pressure relief safety valve, when the pressure exceeds the design pressure, the safety valve opens to release the pressure; automatic overpressure protection control, when the pressure exceeds the set pressure, automatic steam discharge and pressure relief, and displays an alarm.

  4. Low water level alarm device: When the water level is below the specified level, the heating is automatically cut off and an alarm is displayed.

Pulse Vacuum Sterilizer Applications:

Pulse vacuum steriliser is widely used in medical, pharmaceutical and laboratory fields. Its unique sterilisation method through pulse vacuum technology can effectively inactivate microorganisms and spores, ensuring efficient sterilisation of instruments, equipment, pharmaceuticals and so on. Its applications include medical devices, pharmaceutical production, laboratory research, etc. It provides a reliable means to ensure biosafety in healthcare and scientific research.

Pulse Vacuum Sterilizer Specifications:

ModelST-H60PVIST-H80PVIST-H100PVIST-H135PVIST-H150PVIST-H185PVIST-H200PVIST-H300PVIST-H450PVIST-H500PVI
Design Pressure-0.1/0.3MPa
Ultimate vacuum-0.096MPa
Rated Working Pressure0.23Mpa
Sterilizing Temp.105~136℃
Pressure Display Accuracy0.1℃
Max Temp.136℃
Temp. Uniformity≤±0.5℃
Chamber MaterialSUS304 stainless steel
Capacity (L)6080100135150185200300450500
Chamber Size (Φ×L)386×500386×700386×950500×700500×780500×950500×1000
630x1000630×1450630×1620
External Size (L×W×H)(mm)

985×60

0×1450

985×600

×1450

1200×600

×1450

1000×710

×1550

1330×710

×1550

1250×710

×1550

1320×710

×1550

1350×900

×1750

1800×900

×1750

1980×900

×1750

Net Weight105120140225240255265350450500
Power Supply380V 50Hz 5.7Kw380V 50Hz 5.7Kw380V 50Hz 6Kw380V 50Hz 9.35Kw380V 50Hz 9.35Kw380V 50Hz 10.8Kw380V 50Hz 10.8Kw380V 50Hz 12Kw380V 50Hz 20Kw380V 50Hz 20Kw
