Benchtop Multipurpose Centrifuge

Model : CFG-Y21H

Max speed : 21000r/min
Max RCF : 30910×g
Max capacity : 4×800ml Swing Rotor
Sizes(W×D×H)(mm) : 500×680×385
Availability:

Multipurpose centrifuge is used for bacteria, protein precipitation, nucleic acid extraction, subcellular component separation, clinical test sample processing, blood, suitable for medical, life sciences, biopharmaceutical, agricultural sciences, environmental protection and other scientific research units, as well as universities and colleges.

Multipurpose Centrifuge Features:

  1. Adopt large torque brushless frequency conversion motor, maintenance-free, no dust, fast lifting speed.

  2. Induction automatic electric suction door lock, with emergency door opening device; self-inspection and protection of door lock, overspeed, unbalance, etc., safe and reliable.

  3. Using a microcomputer processor for precise control, the high-definition touch screen "Intelligent System" version displays both setting parameters and real-time parameters: Speed, RCF, Time, Rise/Fall rate, Rotor No., Door cover status, etcionion.

  4. Using a unique spring cone sleeve to connect the rotating head and spindle, the rotating head is locked 360 degrees, and the loading and unloading of the rotating head is non directional, fast and simple.

  5. Aero aluminum rotors (except multi-tube frame rotors) and various Teflon adapters are available.

  6. Can store and call 100 sets of programs, with 9 acceleration rates and 10 deceleration rate options.

  7. The whole machine is all-steel structure, stainless steel centrifugal chamber; multi-layer protection design, three-stage vibration reduction, safe and stable.

  8. The instrument door cover is equipped with a hydraulic rod to reduce operating load.

  9. Optional: Automatic recognition of rotor magnetism to avoid misoperation and overspeed operation.

Refrigerated Centrifuge Specifications:

ModelCFG-Y20HR
Max speed21000r/min
Max RCF30910×g
Max capacity4×800ml Swing Rotor
Speed accuracy±10rpm
Time setting1s~99h59min59s
Noise≤66dBA
Power supplyAC110/220V, 50/60Hz
Sizes (W×D×H)(mm)500×680×385
Packing Size (W×D×H)(mm)880×580×560
N.W./G.W. (kg)67/90

Matched Rotors:

Rotor TypeMax SpeedMax VolumeMax RCF
Angle rotor18000rpm30×0.5ml26660×g
Angle rotor15000rpm40×0.5ml22930×g
Angle rotor21000rpm12×1.5/2ml30910×g
Angle rotor18000rpm24×1.5/2ml29670×g
Angle rotor13500rpm30×1.5/2ml19340×g
Angle rotor13000rpm48×1.5/2ml17930×g
Angle rotor16000rpm16×5ml22020×g
Angle rotor16000rpm12×7ml21380×g
Angle rotor16000rpm6×10ml21500×g
Angle rotor15000rpm12×10ml22680×g
Angle rotor13000rpm8×15ml17790×g
Angle rotor10000rpm12×15ml11840×g
Angle rotor5000rpm24×15ml3500×g
Angle rotor5000rpm30×15ml3830×g
Angle rotor12000rpm8×20ml14510×g
Angle rotor14000rpm6×30ml19060×g
Angle rotor13000rpm6×50ml(sharp bottom)18840×g
Adaptor6×15ml(sharp bottom)
Angle rotor13000rpm6×50m(Round bottom)18730×g
Angle rotor8000rpm8×50ml8090×g
Angle rotor5000rpm12×50ml3860×g
Angle rotor5000rpm24×50ml4640×g
Angle rotor12000rpm4×100ml14850×g
Angle rotor12000rpm6×100ml16390×g
Angle rotor8000rpm4×250ml9090×g
Angle rotor7000rpm6×250ml8050×g
Angle rotor5000rpm12×100ml4640×g
Swing Rotor15000rpm4×5ml19920×g
Swing Rotor4000rpm4×25×5/7ml3450×g
Swing Rotor4000rpm4×800ml(round)3450×g
Biosafety cover
Adaptor4×500ml(falcon)
Adaptor4×250ml(falcon)
Adaptor4×24×5/7ml vacuum tube
Adaptor4×19×10ml vacuum tube
Adaptor4×14×10/15ml
Adaptor4×5×50ml
Swing Rotor4000rpm4×500/600ml(round)3530×g
Biosafety cover
Adapter4×18×5/7ml vacuum tube
Adapter4×14×10ml vacuum tube
Adapter4×9×10/15ml
Adapter4×3×50ml
Swing Rotor4000rpm4×500/600ml(rectangle)3450×g
Biosafety cover
Adapter4×20×5/7ml
Adapter4×16×10ml
Adapter4×12×10/15ml
Adapter4×5×50ml
Swing Rotor4000rpm4×7×50ml3470×g
Swing Rotor4000rpm4×4×96 well2940×g
Swing Rotor4000rpm2×4×96 well2490×g
Swing Rotor4000rpm2×3×48 well2300×g
Swing Rotor5000rpm4×1×50ml4730×g
Swing Rotor5000rpm4×1×100ml4730×g
Swing Rotor4000rpm4×2×100ml3020×g
Swing Rotor4000rpm4×2×50ml3200×g
Swing Rotor4000rpm4×8×15ml3200×g
Swing Rotor4000rpm4×16×5ml vacuum tube2530×g
Swing Rotor4000rpm4×16×7ml vacuum tube2890×g
Swing Rotor4000rpm4×12×10ml vacuum tube2880×g
Swing Rotor4000rpm4×milk test bottle3830×g
Swing Rotor4000rpm4×24×5ml vacuum tube2840×g
Swing Rotor4000rpm4×24×7ml vacuum tube3140×g
Swing Rotor4000rpm4×18×10ml vacuum tube3140×g
Swing Rotor4000rpm4×30×7ml vacuum tube3140×g
Swing Rotor4000rpm4×40×7ml vacuum tube3270×g
Swing Rotor4000rpm4×57×7ml vacuum tube3270×g
Swing Rotor4000rpm4×600ml Centrifugal blood bag
