Basic Peristaltic Pump, BPP-100S

Model : BPP-100S

Rotating Speed : 0.1~150rpm
Speed Resolution : Speed <100rpm, 0.1pm; Speed>100, 1rpm
Adjustment Method : Physical button adjustment or external control adjustment
External Size(LxWxH)(mm) : 220×153×138
Basic peristaltic pump for filtration. From laboratory vacuum pumps to peristaltic pumps, there is a wide range of general purpose and manual pumps to choose from.
Availability:
Quantity:

Basic Peristaltic Pump Features:

  1. Stepper motor subdivision drive, using external drive, has high precision, smooth operation and low vibration.

  2. Stainless steel casing, physical buttons, and green digital display are unique and have a wider range of applications. Forward rotation, reverse rotation, and external control are indicated by 3 indicator lights; when stopped, the corresponding indicator light in the direction flashes.

  3. The physical buttons adjust the speed, direction, and start/stop, making the operation simple and convenient; there is also a full-speed button for quick filling or emptying.

  4. It has a power-off memory function. After power-off, power on again to maintain the data status before power-off.

  5. Supports wireless control and can be used with our company's remote control to achieve remote wireless control.

  6. Supports mobile phone control and cooperates with Internet of Things technology to achieve artificial intelligence creontrol.

  7. Support external signal control such as 0-10KHz, 0-5V, 0-10V, 4-20mA, etc.

  8. It can be used with optional accessories to achieve small batch filling and distribution;

Basic Peristaltic Pump Specifications:

ModelBPP-100S
Rotating Speed0.1~150rpm
Speed ResolutionSpeed <100rpm,0.1pm; Speed>100,1rpm
External Control FunctionStart, stop, direction (switch signal); speed (0-5V, 0-10V, 4-20mA, 0-10KHz optional)
Adjustment MethodPhysical button adjustment or external control adjustment
Communication FunctionAdapted to RS485 communication module, capable of RS485 communication standard (MODBUS protocol)
VoltageAC90-265V, 50Hz/60Hz
Power Consumption<30W
Working EnvironmentAmbient temperature 0~40℃, relative humidity <80%
External Size (W×D×H)(mm)220×153×138
Weight (Excluding Pump Head)2.35kg
Protection LevelIP31

Configuration

ModelApplicable pump headApplicable hoseFlow range (ml/min)Number of channels
BPP-100SYZ151513# 14# 19#16# 25# 17#18#0.007-5701
YZ251515#24#0.17-4051
DG-(1,2,4) 6 rollersWall thickness 0.8-1mm, inner diameter ≤3.17mmSingle channel 0.0025-721,2,4
DG-(1,2,4) 10 rollersSingle channel 0.002-481,2,4
