Visible Spectrophotometer Specification:
| Model | SP-V5000 | SP-V5100 |
| Optical System | Single Beam detection |
| Display | 128×64 LCD |
|
| Wavelength Setting | Manual Turn Knob | Automatic |
| Scanning Speed | No | Fast-Medium-Slow |
| Bandwidth (nm) | 4 | 2 |
| Wavelength Range | 325–1000 nm |
| Photometric Range | -3.0 to 3.0 A, 0–200%T, 0–9999C |
| Wavelength Accuracy (nm) | ±2 nm |
| Wavelength Repeatability (nm) | 1 | 0.5 |
| Photometric Accuracy | ±0.5%T |
|
| Photometric Repeatability | ≤0.2%T |
|
| Photometric Mode | T, A, C, F |
|
| Stray Light | ≤0.2%T | ≤0.1%T |
| Stability | ±0.002A/h @ 500nm | ±0.001A/h @ 500nm |
| Interface | USB Port & Parallel Port (Printer) |
| Software | Optional |
| Sample Rack | Standard 10 mm 4-position |
| Power Supply | AC 85–250 V, 50/60 Hz |
| External Size(W×D×H) | 420×280×180 mm |
| Shipping Size(W×D×H) | 600×460×330 mm |
| N.W./G.W. | 8/13 kg |
Single Beam Visible Spectrophotometer Features:
SP-V5000 is a visible spectrophotometer with manual wavelength setting. Due to its basic design and affordability, this model is the best choice for routine analysis and general experiments. Excellent performance, wide range of applications and easy operation
Microprocessor-controlled, auto-zeroing and automatic 100%T adjustment at the push of a button
LCD display for direct readout of transmittance, absorbance and concentration
Visible spectrophotometer utilizes a 1200-line grating for high resolution, low stray light and high parameter accuracy.
USB port for data output, which can be connected to a PC for editing with specific software.
When connected to a micro-printer, the date can also be printed via the parallel port.
The compact design of the SP-V5000 saves bench space.
All necessary components, such as the 120 mm wide sample chamber and the long optical path monochromator, have been retained.
Visible spectrophotometer directly displays absorbance, transmittance, concentration and coefficients by switching between different modes.
Details of Visible Spectrophotometer:
The visible spectrophotometer's overall compact design and small footprint make it widely used in chemical analysis and life sciences.
Multiple sample holders to hold and analyse multiple samples simultaneously
What is Automatic Wavelength Setting Visible Spectrophotometer?
A: With Automatic Wavelength Setting, users no longer need to rotate traditional mechanical knobs to align with the target wavelength. Simply enter the desired wavelength value on the instrument's numeric keypad or touchscreen, and the instrument's internal precision stepper motor will instantly start, automatically rotating theoptical grating to the precise position.
