Touch Screen UV-VIS Spectrophotometer Application:
Pharmaceuticals and Biotechnology: Drug dissolution testing; nucleic acid/protein concentration determination.
Environmental Monitoring: Quantitative analysis of pollutants such as heavy metals, COD, and ammonia nitrogen in water.
Chemicals and Materials: Transmittance/absorbance scanning of samples such as dyes, coatings, and films.
Food and Cosmetics: Detection of additives, preservatives, and vitamin content.
Scientific Research and Education: Teaching and research in high-precision spectroscopic analysis in university laboratories and research institutes.
Quality Control (QA/QC): Rapid batch inspection of raw materials and finished products on the production line.
Touch Screen UV-VIS Spectrophotometer Feature:
10.1-inch color touchscreen, allowing measurements to be completed without an external computer.
Suspended optical system + reinforced and thickened aluminum base plate eliminates the effects of vibration and deformation.
Dual-layer design achieves complete isolation between the optical path and circuitry, significantly improving resolution and stability.
ARM12 high-performance processor, capable of storing 5,000 test data points or 500 working curves.
Supports data export to USB flash drive, and multiple data formats such as Excel, TXT, BMP images, and .csv, .qua, .tet, and .bmp files to meet various analytical needs.
Built-in 8GB standard memory, equipped with RS-232C (printer), USB drive (online), and USB HOST (USB flash drive).
Optional fully automated sampling flow path system enables unattended continuous measurement, greatly improving ease of use.
Optional 8-unit rotating automatic sample cell holder ensures the optical path is perfectly centered when passing through the cuvette, improving measurement accuracy and repeatability.
Touch Screen UV-VIS Spectrophotometer Specification:
Model | SP-UV3200TS | SP-UV3200STS |
Optical System | Split Beam detection |
Display | 10.1-inch high-resolution capacitive touch LCD screen |
Bandwidth (nm) | 2 | 0.5/1/2/4/5 adjustable |
Light Source | Imported Deuterium Lamp and Tungsten Lamp |
Photometric Range | -3.0 to 3.0 A, 0-200%T, 0-9999C |
Wavelength Accuracy | ±0.3 nm |
Wavelength Repeatability | 0.1 nm |
Stray Light | 0.05% (220nm) |
Scanning Speed | Adjustable with optional software |
Stability | ±0.001 nm |
Data Storage | Standard 8 GB memory |
Interface | RS-232C, USB drive, USB Host |
Software | Optional |
Optional Acessory | Built-in Automatic Sampling Flow Path System |
8-Cell Automatic Cuvette Holder |
Power Supply | AC 220/110V, 50/60Hz |
Consumption | 120 W |
External Size (W×D×H) | 580×450×210 mm |
Shipping Size (W×D×H) | 800×645×365 mm |
N.W./G.W. | 21/26 kg |
FAQ for Touch Screen UV-VIS Spectrophotometer:
Q1: Why choose Split beam"? (For routine quality inspection and cost-effective applications)
A: It solves the biggest pain point of data drift caused by the unstable light source of single-beam instruments, while its price is usually much lower than that of traditional dual-beam instruments, giving customers excellent cost performance.
Q2: What kinds of applications require our optional accessories?
A: Built-in Automatic Sampling Flow Path System for routine high-throughput sampling tests such as industrial quality inspection and environmental monitoring.
8-Cell Automatic Cuvette Holder for research and development, multi-component parallel comparison, enzyme kinetic analysis;
