5. OLED display screen: Clear to see and easy to operate.
6. Segmented positioning of blade holder: Three section quick positioning to maximize the utilization of blade.
7. Blade holder's angle adjustment: The angle can be adjusted from 0 to 10 degrees, and the front and back position of the blade holder can be adjusted.
8. High and low profile blade holder: Optional high and low profile blade holder.
9. Double Locking System: Upper lock enables quick operation; lower lock secures the handwheel at any position.
Specification:
Model
MT-S5500
Section Thickness Range
0.25-100 μm
Section Thickness Setting
0.25-2.5 μm, in 0.25 μm increments
2.5-5 μm, in 0.5 μm increments
5-10 μm, in 1 μm increments
10-30 μm, in 2 μm increments
30-60 μm, in 5 μm increments
60-100 μm, in 10 μm increments
Trimming Thickness Range
1-600 μm
Trimming Thickness Setting
1-10 μm, in 1 μm increments
10-20 μm, in 2 μm increments
20-50 μm, in 5 μm increments
50-150 μm, in 10 μm increments
150-600 μm, in 50 μm increments
Max.Specimen Size
80×65 mm
Precision Error
±1%
Retraction Range
0-100 μm(0 means no retraction fuction)
0-5-10-15-100 adjustable
Total Horizontal Specimen Feed
30 mm
Vertical Specimen Stroke
70 mm
Feeding Speed
2000 μm/s
Number of Section and Trimming
0-9999
Memory Points
2 position can be set
Movement Range of Blade Holder's Base
0-65 mm (front-to-back)
Movement Range of Blade Holder
0-26 mm (left-to-right)
Specimen Orientation
X/Y axis 8°, Rotation 360°(optional)
Power Supply
AC 110 V - 120 V
AC 220 V - 240 V
Power Draw
100 VA
External Size (W×D×H)
595×465×295 mm
Shipping Size (W×D×H)
690×490×640 mm
N.W. /G.W.
28/50 kg
Advantage:
1. Number of sections: Section and trimming counts are clearly displayed.
2. The memory position: Multiple memory positions of specimen holder.
3. Quick Positioning: One click to return to the user-defined position.
5. OLED display screen: Clear to see and easy to operate.
6. Segmented positioning of blade holder: Three section quick positioning to maximize the utilization of blade.
7. Blade holder's angle adjustment: The angle can be adjusted from 0 to 10 degrees, and the front and back position of the blade holder can be adjusted.
8. High and low profile blade holder: Optional high and low profile blade holder.
9. Double Locking System: Upper lock enables quick operation; lower lock secures the handwheel at any position.
As a professional lab and medical equipment manufacturer, Scitek Global is certified by ISO 9001, ISO 13485, ISO 45001 and ISO 14001. Almost all our products are certified by ETL, CE and FDA .
Scitek Global looks forward to establishing cooperation with more distributors all over the world, and working together to create greater customer value.
