| Model | PPM-C | |
|---|---|---|
| CO₂ | Measure Range | 0~1500ppm |
| Accuracy | 3%ppm | |
| Leaf Temperature | Measure Range | 0~50℃ |
| Accuracy | ±0.5℃ | |
| Air Temperature | Measure Range | 0~50℃ |
| Accuracy | ±0.5℃ | |
| PAR | Measure Range | 0~2500μmol·m-²•s-¹ |
| Accuracy | <5μmol·m-²•s-¹ | |
| RH (Chamber humidity) | Measure Range | 0~100% |
| Accuracy | 0.02 | |
| Power Supply | AC110~220V, 50/60Hz | |
| Shipping Size(W×D×H)(mm) | 720x520x320 | |
| G.W. (kg) | 13 | |
Accessories:
Host machine, handle, Gas path pipes, Charger, SD card, Power line, Backpack
The plant photosynthesis meter applies for measuring Photosynthesis rate of crops, fruits and vegetables, grass etc.
Special Setting: Advanced MCU, lattice LCD widescreen display, menu display and cursor operation.
Use‐friendly: Small in size, light‐weight, portable, single‐person operation, clear connection of gas circuit and electrical circuit, the leaf chamber open and lock automatically.
Excellent Performance: High stability, accuracy, repeatability, and good time response. It is able to measure simultaneously Pn, CO2, PAR, T etc.
Widely Application: Equip different type leaf chamber, it can widely apply for field crop, fruits and vegetables, forest and wood, grass etc. Equip standard maintain‐free Li‐Ion, AC/DC are available, RS232 available.
