Application:
Automated slide stainers are primarily used as biomedical tools, typically in medical laboratories. This automatic slide stainer provides staining flexibility for staining up to hundreds of slides simultaneously. Suitable for use in histopathology, haematology and cytopathology studies, it is the ideal tool to facilitate the preparation of slides for diagnostic and research purposes.
Advantage:
1. 7-inch intelligent touch color screen for real-time display of working status, with clear and intuitive visualization.
2. Supports dye name entry and viewing, along with real-time status monitoring for more intuitive data presentation.(Only for TS-II)
3. Synchronous display of working stations enables clear and convenient progress tracking.
4. Intelligent hot air control for automatic drying.
5. Imported solenoid valves with intelligent control enable fully automatic water intake and drainage for thorough cleaning.
6. Built-in circulating air purification system, efficiently absorbs harmful gases.(Only for TS-I)
Specification:
Model | TS-I | TS-II |
Number of Processing chambers | 14 (1 for rinsing, 1 for drying) | 18 (1 for rinsing, 1 for drying) |
Single Chamber Capacity | 1500 mL | 750 mL |
Processing Time per Station | 0-59 min 59 sec (adjustable) | |
Dripping Time | adjustable within 0-30 s | |
Temporary Rinse Time | 0~59 seconds | |
Number of Slides Processed Simultaneously | 70 pcs | 50 pcs |
Programmable | 20 sets | |
Programmable Immersion Sequence | 1-28 | 1-36 |
Power Supply | AC100 V - 120 V / AC 220 V- 240 V 50 Hz / 60 Hz | |
Consumption | 500 W | |
External Size (W×D×H) | 1380×420×470 mm | |
N.W. | 70 kg | 75 kg |
Application:
Automated slide stainers are primarily used as biomedical tools, typically in medical laboratories. This automatic slide stainer provides staining flexibility for staining up to hundreds of slides simultaneously. Suitable for use in histopathology, haematology and cytopathology studies, it is the ideal tool to facilitate the preparation of slides for diagnostic and research purposes.
Advantage:
1. 7-inch intelligent touch color screen for real-time display of working status, with clear and intuitive visualization.
2. Supports dye name entry and viewing, along with real-time status monitoring for more intuitive data presentation.(Only for TS-II)
3. Synchronous display of working stations enables clear and convenient progress tracking.
4. Intelligent hot air control for automatic drying.
5. Imported solenoid valves with intelligent control enable fully automatic water intake and drainage for thorough cleaning.
6. Built-in circulating air purification system, efficiently absorbs harmful gases.(Only for TS-I)
Specification:
Model | TS-I | TS-II |
Number of Processing chambers | 14 (1 for rinsing, 1 for drying) | 18 (1 for rinsing, 1 for drying) |
Single Chamber Capacity | 1500 mL | 750 mL |
Processing Time per Station | 0-59 min 59 sec (adjustable) | |
Dripping Time | adjustable within 0-30 s | |
Temporary Rinse Time | 0~59 seconds | |
Number of Slides Processed Simultaneously | 70 pcs | 50 pcs |
Programmable | 20 sets | |
Programmable Immersion Sequence | 1-28 | 1-36 |
Power Supply | AC100 V - 120 V / AC 220 V- 240 V 50 Hz / 60 Hz | |
Consumption | 500 W | |
External Size (W×D×H) | 1380×420×470 mm | |
N.W. | 70 kg | 75 kg |
