Fully Automated Microtome Specifications:
| Model | MT-A3400 |
|---|
| Section Thickness Setting Range | 0.25~100μm |
| 0.25~2.5μm, increment 0.25μm |
| 2.5~5μm, increment 0.5μm |
| 5.0~10μm, increment 1μm |
| 10~30μm, increment 2μm |
| 30~60μm, increment 5μm |
| 60~100μm, increment 10μm |
| Trimming Thickness Setting Range | 1~600μm |
| 1~10μm, increment 1μm |
| 10~20μm, increment 2μm |
| 20~50μm, increment 5μm |
| 50~150μm, increment 10μm |
| 150~600μm, increment 50μm |
| Retraction Setting Range | 0~50μm (0 is off) |
| 5-10-15~50 (optional) |
| Minimum Setting of Sectioning Thickness | 0.25μm |
| Horizontal Feed | 28mm |
| Vertical Specimen Stroke | 70mm |
| Specimen Holder Rotation | At any angle within 360 degrees |
| Movement Range of the Base of Blade Holder Base | 0~60mm (front to back) |
| Movement Range of the Blade Press Plate | 0~23mm |
| Specimen Clamp Rotation | At any angle within 360 degrees |
| Specimen Orientation | XY – 8° |
| Maximum Specimen Size | 70×70mm (optional clamp) |
| Feed Speed Adjust | 1500μm/s ~ 3500μm/s |
| Precision Error | ±1% |
| Power Supply | Ac 220V±10% 50Hz (standard model); Ac110V±10% 60Hz |
| Power | 150W |
| Sizes(W×D×H)(mm) | 580×475×340 |
| Shipping Size(W×D×H)(mm) | 700x600x490 |
| N.W./G.W. (kg) | 50/65 |
Fully Automated Microtome Features:
The MT-A3400 fully automated microtome is the first choice for medical and experimental research and industry. Its high cutting accuracy and stable cutting performance make it ideal for use in industries with high demands on slicing technology. It offers excellent performance, comfortable operation and reliable cutting accuracy.
Another outstanding advantage of this automated microtome is its support for adjusting the cutting window according to the sample size. This feature allows users to cut samples accurately and quickly during operation.
Streamlined design and aesthetic appearance
Adjustable slicing speed and intelligent control mechanism for loading and unloading
Advanced drive system and screw moving parts ensure excellent slicing performance.
Continuously adjustable slicing speed
Emergency brake, overload protection and other safety functions.
Precise balance adjustment of the handwheel, which can be locked at any position to ensure safe operation;
Semi-automatic slicing or trimming is still possible when the automatic slicing controller is turned off;
8° XY-axis adjustment for precise positioning of the sample head.
